EasyGen 3000 model number 8440-2163 is an easYgen-3400-5, this model is made of metal and is mounted and housed in a cabinet. This model has multilingual capability and can be changed to many different languages such as Russian, Italian and Japanese.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 8440-2163 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8440-2163
  • SKU: 84402163WO
  • Manufacturer: Woodward
  • Series: EasyGen-3000 Series

8440-2163

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
EasyGen 3000 model number 8440-2163 is an easYgen-3400-5, this model is made of metal and is mounted and housed in a cabinet. This model has multilingual capability and can be changed to many different languages such as Russian, Italian and Japanese.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 8440-2163 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8440-2163
  • SKU: 84402163WO
  • Manufacturer: Woodward
  • Series: EasyGen-3000 Series

8440-2163 Technical Specifications

Manufacturer Woodward
Measurable Alternator Windings 3p-3w, 3p-4w, 1p-2w, 1p-3w
Operation Temp -20 - 70C
Power Setting Range 0.5 - 99,999.9 kW/kvar
Power Supply 12/24 Vdc ( 8 to 40 Vdc)
Resolution 11 Bit

Product Description

8440-2163 is an easYgen 3000 series genset control, offering complete engine-generator protection and control in rental or mobile genset applications. There are several available models in this Woodward series. Part number 8440-2163 is the 3400-5/P1-K32 model.



This model has 5A CT inputs. It is a Package 1 model in a metal housing, designed for rear panel mounting. There is no built-in HMI on this model. easYgen control models with a built-in display (in plastic housing) are available through AX Control.



The easYgen K32 rental genset applications models have additional features not included in the standard 3400 genset controls. The 3400 K32 models are compatible with the Woodward LS-5 series circuit breaker controls. Additionally, they have four blocks of switchable parameter settings. Sixteen configurable parameters are in each block.



Along with these new features, part 8440-2163 still has all the same functionality as the standard 3400-P1 genset control. Load transfer, breaker control, soft loading/unloading, and much more, are all still supported for up to 32 units.



8440-2163 has a Class 1 accuracy rating. It has a 50/60 Hz (40 to 85 Hz) measuring frequency and a primary setting range of 50 to 650,000 Vac. This genset control has both discrete and analog I/Os. Full product specs can be found in Woodward easYgen product specification sheet 37553D and in easYgen 3000 manual 37528.

  • EasyGen-3400-5
Reviews For 8440-2163
Internal Review

The Woodward control model 8440-2163 is the only easYgen-3400-5 model, as such not much information is known about this part but some information can be found in the attached manual on this page. - AX Control Technician

Repair Services For 8440-2163

Type Lead Time Price Action
Repair Service 1-2 weeks $952

Our highly skilled technicians can repair your 8440-2163. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
