EasyGen 3000 model 8440-2095 is made up of plastic and has a display screen. The model has several interface connectors, such as two CAN bus connectors. The controller has a display screen that displays status rather than individual LCDs.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 8440-2095 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8440-2095
  • SKU: 84402095WO
  • Manufacturer: Woodward
  • Series: EasyGen-3000 Series

8440-2095

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
EasyGen 3000 model 8440-2095 is made up of plastic and has a display screen. The model has several interface connectors, such as two CAN bus connectors. The controller has a display screen that displays status rather than individual LCDs.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 8440-2095 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8440-2095
  • SKU: 84402095WO
  • Manufacturer: Woodward
  • Series: EasyGen-3000 Series

8440-2095 Technical Specifications

Ambient Humidity 95%, non-condensing
Front Panel Dimensions 282W X 217H X 99D mm
Manufacturer Woodward
Max. power consumption per path < 0.15 W
Power Supply 12/24 Vdc ( 8 to 40 Vdc)
Primary Setting Range 50 - 650,000 Vac

Product Description

Genset controller module 8440-2095 is one of the models that is labeled as an easYgen-3500-1 model and is used for complex breaker applications. The 8440-2095 model can be used as part of an automatic segment controller, the controller is also made from plastic and has encased softkeys which are used for configuring the operations of the controller.

The controller has many different inputs and outputs many of which are specifically used for easYgen-3500-P2 models which this controller is not. There are many differences between models such as an easYgen-3500-P2 and easYgen-3500-1 one of which is that the easYgen-3500-P2 models have counter pulses which the easYgen-3500-1 models do not. If you wish to connect a series of gensets the best model to choose is an easYgen-3500 model such as the 8440-2095 model with LS-5 applications which will help with multi-grid multi-segment applications.

One key feature of the 84402-95 model is the interactive screen which is a five-point seven-inch, three-hundred twenty by two-hundred forty mm pixilated color graphic LCD screen, which has a clear menu structure which is vital when being used to help with the operation and navigation of the controller.

When using the easYgen-3500 models there are two packages, the P1 package, and the P2 package, there are different discrete alarm inputs that are within the two packages, for the P1 package there are twelve discrete alarms, nine of which can be configured, which would be ideal for the 8440-2095 model; with the P2 package, there are twenty-three discrete alarms, twenty of which can be configured.

  • EasyGen-3500-1
Reviews For 8440-2095
Internal Review

The 8440-2095 model is one of the easYgen-3500-1 models, this model can specifically be used with LS-5 applications which can be used with multi-grid multi-segment applications. - AX Control Tech Team

Repair Services For 8440-2095

Type Lead Time Price Action
Repair Service 1-2 weeks $940

Our highly skilled technicians can repair your 8440-2095. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
