Woodward model 8440-2087 is the second of the easYgen-3400XT models but is the P2 version, this version is made of metal and used for back panel installation. The 8440-2087 model is equipped with peak shaving operation capabilities.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 8440-2087 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8440-2087
  • SKU: 84402087WO
  • Manufacturer: Woodward
  • Series: EasyGen-3000 Series

8440-2087

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
Woodward model 8440-2087 is the second of the easYgen-3400XT models but is the P2 version, this version is made of metal and used for back panel installation. The 8440-2087 model is equipped with peak shaving operation capabilities.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 8440-2087 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8440-2087
  • SKU: 84402087WO
  • Manufacturer: Woodward
  • Series: EasyGen-3000 Series

8440-2087 Technical Specifications

Front Panel Dimensions 282W X 216H X 96D mm
Measuring Frequency 50/60Hz (40 - 85 Hz)
Multi-lingual English, German, Spanish, French, Italian, Portuguese, Japanese, Chinese, Russian, Turkish, Polish, Slovakian, Finnish, Swedish
Power Supply 12/24 Vdc ( 8 to 40 Vdc)
Primary Setting Range 50 - 650,000 Vac
Relay Outputs Isolated

Product Description

The Woodward 8440-2087 model is from the EasyGen 3000 series and is alternatively known as the easYgen-3400XT-P2 model, the device is housed in sheet metal and does not come with an LCD screen that can be used regarding the information on operating modes as well as potential alarm classes, because of the lack of screen another remote control must be connected to the device.

As this device is an easYgen-3400 model it will have LEDs on the front of the control panel, and there is a COMMS and RUN LED on the front of the device. There are four states that your LEDs can be in, for your COMMS LED they will either be not illuminated, blinking green, blinking green/red, or illuminated red; for your RUN LED they will either be not illuminated, blinking green/red, illuminated red or illuminated green, each LED state indicates something different. For example, when the COMMS LED is blinking green it indicates that some data has been received by one of the interfaces.

It is vital to the operation of your controller that you take caution in using the correct voltages, and especially the correct busbar voltages, there are different phases between the P1 and P2 models, the phase for the P1 models are 1-ph and the phase for the P2 models are 3-ph. Be cautious at what temperature you are operating your control as well, operating temperature for the easYgen-3400 models differs slightly compared to the easYgen-3500, the proper operating temperature is negative forty to positive seventy degrees Celsius.

  • EasyGen-3400XT-P2
Reviews For 8440-2087
Internal Review

Model number 8440-2087 is equipped with a configurable PID controller that can be used for many different purposes, such as controlling fuel level, water level as well as pressure. For more information on these functions browse the attached manual. - AX Control Technician

Repair Services For 8440-2087

Type Lead Time Price Action
Repair Service 1-2 weeks $1118

Our highly skilled technicians can repair your 8440-2087. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
