Woodward model 8440-2056 alternatively known as easYgen-3100-5 is part of the EasyGen-3000 series and has a breaker control feature that also monitors breaking. This model also has a dynamic mains stabilization capability.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 8440-2056 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8440-2056
  • SKU: 84402056WO
  • Manufacturer: Woodward
  • Series: EasyGen-3000 Series

8440-2056

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
Woodward model 8440-2056 alternatively known as easYgen-3100-5 is part of the EasyGen-3000 series and has a breaker control feature that also monitors breaking. This model also has a dynamic mains stabilization capability.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 8440-2056 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8440-2056
  • SKU: 84402056WO
  • Manufacturer: Woodward
  • Series: EasyGen-3000 Series

8440-2056 Technical Specifications

Input Range 12/24 Vdc ( 8 to 40 Vdc)
Measuring Frequency 50/60Hz (40 - 85 Hz)
Multi-lingual English, German, Spanish, French, Italian, Portuguese, Japanese, Chinese, Russian, Turkish, Polish, Slovakian, Finnish, Swedish
Power Supply 12/24 Vdc ( 8 to 40 Vdc)
Primary Setting Range 50 - 650,000 Vac
Relay Outputs Isolated
Setting Range 1 - 32,000 A

Product Description

The 8440-2056 genset control unit is in the easYgen 3000 series. This model is one of the 3100 versions, so it does not have a direct, built-in HMI. It is intended for the cabinet back mounting, with programming, monitoring, and control features accessed via PC (ToolKit software). This particular model has 5A CT inputs and three PID controllers (freely configurable). Part 8440-2056 is in a metal housing.

Genset control units in this Woodward series are designed for use in either single or multiple unit operations. In multiple unit operations, up to 32 gensets can be connected with automatic sequencing. Many load management features are supported for the connected units, such as load-dependent start/stop, mains parallel operation, open/closed transition, and more.

Control functions of models 8440-2056 are highly customizable to suit the needs of various applications. There are four operating modes available: Automatic, Manual, Stop, and Test (Load/No Load). Manual breaker control is accomplished through the configuration of the voltage/frequency controls. Woodward easYgen 3000 manual 37258P contains a comprehensive list of control functions available with this genset control unit.

8440-2056 can record up to 300 events with its real-time clock event recorder. It has counters for operating hours, starts, maintenance, etc; and it supports start/stop logic for both diesel and gas engines.

  • EasyGen-3100-5
Reviews For 8440-2056
Internal Review

The 8440-2056 module has many features, one of these features is a breaker control, which helps with phase matching synchronization/slip frequency, breaker monitoring, and open-close controls, all of these functions allow for the 8440-2056 controller to function as proposed. - AX Control Technician

Repair Services For 8440-2056

Type Lead Time Price Action
Repair Service 1-2 weeks $1112

Our highly skilled technicians can repair your 8440-2056. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
