The easYgen-3000 8440-2052 is part of the Woodward Genset Controller series. This model has a configurable voltage/frequency feature and allows for manual control. This model also has a fast configuration by partially setting files.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 8440-2052 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8440-2052
  • SKU: 84402052WO
  • Manufacturer: Woodward
  • Series: easYgen-3000 Series

8440-2052 Technical Specifications

Analog Inputs (non isolated) freely scalable
Back Panel Dimensions 250W X 227H X 50mm D
Contact Material AgCdO
Front Panel Dimensions 282W X 216H X 96D mm
Intrinsic Consumption Max. 17 W
Measurable Alternator Windings 3p-3w, 3p-4w, 1p-2w, 1p-3w
Measuring Frequency 50/60Hz (40 - 85 Hz)

About the 8440-2052

With control functions such as load sharing, breaker control logic, AMF (auto mains failure) and stand-by operation, and single or multiple unit operations for up to 32 genset units, part 8440-2052 is optimized for use in a variety of applications. This genset control unit is part of the easYgen-3000 series by Woodward.

Part 8440-2052 is a 3200-P2 model. As a 3200 model, this control has a built-in operator interface on the front panel of the unit’s plastic housing. Package 2 (P2) models come with an additional control feature of three PID controllers, which are freely configurable. It has 5A CT inputs and is designed for front panel mounting. Part 8440-2052 has a 12/24 VDC (8 to 40 VDC) power supply.

This easYgen genset controller has both analog and discrete I/Os

  • Up to 12 configurable discrete I/Os
  • 32 external discrete I/Os (each) via CANopen
  • 3 configurable analog inputs
  • 16 external analog inputs via CANopen
  • 4 external analog outputs via CANopen

easYgen model 8440-2052 measures speed input using magnetic / switching pickup, with a 50/60 Hz (40 to 85 Hz) measuring frequency. Speed, frequency, voltage, power factor, excitation, and many more setpoints may be configured for maximum generator, engine, and mains protection. There are 12 discrete alarm outputs, 10 of which are configurable.

Configuration may be done via PC (using ToolKit software) or directly through the control unit itself using the built-in HMI. This operator interface has a keypad, and a color LCD, and access may be managed with the multi-level password protection capabilities of the 8440-2052 model. There are fourteen languages available with the software. Additional product specs may be found in easYgen-3000 manual 37258P.

Reviews For 8440-2052

Internal Review
(5.0)

The Woodward EasyGen-3000 8440-2052 model is equipped with operation modes features, that will help control the module with discrete inputs. - AX Control Tech Team

  • EasyGen-3200-5

Repair Services For 8440-2052

Type Lead Time Price Action
Repair Service 1-2 weeks $832

Our highly skilled technicians can repair your 8440-2052. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
