8440-1993

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
The 8440-1993 is part of the EasyGen 3000 Genset Controller series. This series has numerous but its primary function is to be a main series connector and communicator. This is shown through its ability to connect with thirty-two different units at once.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 8440-1993 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8440-1993
  • SKU: 84401993WO
  • Manufacturer: Woodward
  • Series: EasyGen-3000 Series

8440-1993

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
The 8440-1993 is part of the EasyGen 3000 Genset Controller series. This series has numerous but its primary function is to be a main series connector and communicator. This is shown through its ability to connect with thirty-two different units at once.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 8440-1993 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8440-1993
  • SKU: 84401993WO
  • Manufacturer: Woodward
  • Series: EasyGen-3000 Series

8440-1993 Technical Specifications

Accuracy Class 0.5
Ambient Humidity 95%, non-condensing
Contact Material AgCdO
Manufacturer Woodward
Multi-lingual English, German, Spanish, French, Italian, Portuguese, Japanese, Chinese, Russian, Turkish, Polish, Slovakian, Finnish, Swedish
Relay Outputs Isolated
Setting Range 1 - 32,000 A

Product Description

Easily control multiple connected gensets with the easYgen 3000 series model 8440-1993. This genset control unit was manufactured by Woodward. Part 8440-1993 is a 3200 model, which means it is in a plastic housing and has a built-in operation panel (3100 models are in a metal housing and have no display panel). The operation panel has a keypad and a 5.7” LCD.



This easYgen controller offers protection from a wide range of conditions, including generator and engine over-/under speed, engine excitation, unbalanced load or voltage, and speed/frequency mismatch to name a few. The 8440-1993 genset control also has several load management features, such as peak shaving, backup power generator, and import/export control.



Operations are monitored from the included operation panel. This unit has multi-lingual capabilities, with fourteen supported languages. Configuration of set points such as trip levels, alarm classes, speed, frequency, and more is done through this HMI. Direct access to configuration and control functions is managed using multi-level password protection.



A few additional features of easYgen model 8440-1993 include:

  • Timer or coolant temp warm-up control
  • kWh meter and kvarh meter
  • Configurable analog and discrete I/Os
  • Phase matching synchronization
  • Slip frequency synchronization



Woodward easYgen 3000 manual 37258 has full detail on 8440-1993 features and applications.

  • EasyGen-3200-5-P1
Reviews For 8440-1993
Internal Review

The 8440-1993's low availability is the cause for its less than perfect rating. With that aside, however, the 8440-1993 holds within it some rather useful tools and equipment. Such as its automatic base loading/peak shaving, as well as import and export control. -AX Control Tech Team

Repair Services For 8440-1993

Type Lead Time Price Action
Repair Service 1-2 weeks $1156

Our highly skilled technicians can repair your 8440-1993. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
