This Woodward 8440-1992 model is just one of the Genset controllers from the EasyGen-3000 series and is designed to be used as the main series connection. This model is also labeled as an easYgen-3200-5-P1 model, which means it is plastic rather than sheet metal.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

3 Year Warranty: Learn More
Sell Surplus: Have a 8440-1992 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8440-1992
  • SKU: 84401992WO
  • Manufacturer: Woodward
  • Series: EasyGen-3000 Series

8440-1992

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
This Woodward 8440-1992 model is just one of the Genset controllers from the EasyGen-3000 series and is designed to be used as the main series connection. This model is also labeled as an easYgen-3200-5-P1 model, which means it is plastic rather than sheet metal.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

3 Year Warranty: Learn More
Sell Surplus: Have a 8440-1992 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8440-1992
  • SKU: 84401992WO
  • Manufacturer: Woodward
  • Series: EasyGen-3000 Series

8440-1992 Technical Specifications

Accuracy Class 0.5
Burden < 0.10 VA
Front Panel Dimensions 282W X 216H X 96D mm
Manufacturer Woodward
Measuring Frequency 50/60Hz (40 - 85 Hz)
Operation Temp -20 - 70C
Power Supply 12/24 Vdc ( 8 to 40 Vdc)

Product Description

This genset control supports a range of features for the monitoring, control, and protection of multiple gensets. Part 8440-1992 is a 3200 model in the Woodward easYgen 3000 series. Like the other 3200 models, 8440-1992 is in plastic housing. This easYgen model has a 12/24 Vdc power supply. 8440-1992 is a P1 version. The P1 package has a maximum of 16 each external discrete inputs/outputs via CANopen.

Woodward easYgen 8440-1992 has a 5.7” LCD screen and touchpad for direct configuration and control of the unit and connected gensets. There are fourteen available languages including English, Polish, Russian, French, and Spanish. Access to some features is restricted through multi-level password protection (four access levels).

8440-1992 has a range of configurable set points. These include, but are not limited to:

  • Trip levels
  • Trip delays
  • Alarm classes (there are 10 configurable discrete alarm inputs)
  • Speed
  • Frequency
  • Auxiliary excitation

Full details on configuration and supported set points may be found in Woodward easYgen 3000 manual 37258.

Operating mode options are no breaker control, one breaker control (GCB open), one breaker control (GCB open/close), and two breaker control (GCB/MCB open/close).

  • EasyGen-3200-5-P1
Reviews For 8440-1992
Internal Review

The 8440-1992 is part of the GenSet controller series which is from the Woodward EasyGen 3000 series. The 8440-1992 was built to be a main-series controller unit. It achieves this by containing up to thirty-two units of load sharing. - AX Control Technician

Repair Services For 8440-1992

Type Lead Time Price Action
Repair Service 1-2 weeks $1344

Our highly skilled technicians can repair your 8440-1992. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
