8440-2323

Q: What is the function of the 8440-2323 Interface&#39;s Bypass button?

This 8440-2323 unit&#39;s Bypass button can be used to bypass a current timer for a more stable timer.

5.00 (2)
Click a star to rate this product

5.00 (2)
Click a star to rate this product

The 8440-2323 Automatic Switch Control Interface made for Woodward's DTSC-200 Series.

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a 8440-2323 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: 8440-2323
SKU: WO-59400

Manufacturer: Woodward
Series: DTSC-200 ATS Controls

Description
Repairs
Warranty
Manuals

8440-2323 Technical Specifications

Part Number	8440-2323
Functional Description	Automatic Switch Control Interface
Manufacturer	Woodward
Series	DTSC-200 ATS Controls
Push-Buttons	12 Buttons
Display Type	Liquid Crystal (LCD)
External Compatibilities	IKD Modules
Assembly Type	DTSC-200A
Power Supply	8-35 V DC
Accuracy	Class 1
Housing Connections	2.5 mm² Screw Terminals
RS-232 Status	Not Used

About the 8440-2323

The 8440-2323 Automatic Switch Control Interface made for Woodward's DTSC-200 Series comes equipped with a standard slew of hardware components and component specifications. Some of these would havee to include its:

ModBus Ethernet Port
Multiple Languages
Liquid Crystal Display
Pushbuttons
Woodward Logo

The pushbuttons included on the face of the 8440-2323 Automatic Switch Control Interface include both selective arrow pushbuttons and buttons representing certain values or modes.

8440-2323 Automatic Switch Control Interface LEDs

As a diagnostically-sound Woodward product, the 8440-2323 Automatic Switch Control Interface has numerous indicator LEDs. Some of these include its:

ATS Inhibit LED
LED Comm ok LED
LED S1 ok LED
LED S1 breaker closed LED
LED S2 breaker closed LED
LED Bypass possible LED

An additional LED is stored on this switch interface to indicate that the unit is in settings mode.

Reviews For 8440-2323

Internal Review

(5.0)

The 8440-2323 featured here offers fine diagnostics with both load and engine tests available without the insertion of any separate Woodward products. This 8440-2323 is offered with the Ethernet port Modbus TCP installed, whereas its 8440-2297 sister product does not feature that modification. The 8440-2323 is technically a member of the separate DTSC-200A Series with a unique interface and an LED-based screen. - AX Control Lead Technician
