9905-796

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
9905-796 from Woodward series of Digital Synchronizer and Load Controllers. Features ±3 VDC speed bias output, Open Delta PT Configuration, 120 voltage input, with full functions.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 9905-796 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

9905-796

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
9905-796 from Woodward series of Digital Synchronizer and Load Controllers. Features ±3 VDC speed bias output, Open Delta PT Configuration, 120 voltage input, with full functions.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 9905-796 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

9905-796 Technical Specifications

Dimensions 460.65mm x 264.16mm x 58.42mm
Features Open Delta PT Configuration
Input Voltage 120 Vac
Model DSLC 9905-796
Output Voltage –40 to +70 °C
Standards +3.0 Vdc Speed bias
Storage Temperature –55 to +105 °C
Weight Less than 7lbs.

Product Description

This device is one of the several units available in the Woodward Inc. line of digital synchronizer and load control units. These DSLC units are available from AX Control Inc. as products in our new surplus or reconditioned used inventory. Each unit for sale has been reconditioned and optimized to run as if it were brand new. Our team of on-site, local technicians are responsible for the quick and efficient repairs to refurbish our industrial hardware for sale.

The 9905-796 model of the Woodward DSLC units is one of the more obsolete units. It is a reduced upgrade model, meaning that it is not equipped with any power factor control capabilities or process control functions.

This model’s voltage for the sensing inputs requires a minimum of 65 volts of alternating current, to a maximum intake of 150 V/AC. The nominal amount for this control device is 120 V/AC. The terminals it utilizes are terminals 3 - 5, 6 - 8, 8 - 10, and 10 - 6.

The 9905-796 unit has a PT Configuration that is given an open delta setup. This affects the switchgear configuration (from units designed in either the US or Canada), made up of the two PTs between A-B and C-B phases. The B phase is grounded by the switchgear.

The basic Woodward environmental specifications included in this unit’s design gives it an operational temperature range of -40 to 70 degrees C (-40 - 158 F), and a storage range of -55 to 105 degrees C (-67 - 221 F).


Reviews For 9905-796
Internal Review

The DSLC control provides a safe automatic dead-bus closure function. Deadbus closing permission is granted to only one DSLC control through locking techniques done over the communications network. - AX Control Technicians

Repair Services For 9905-796

Type Lead Time Price Action
Repair Service 1-2 weeks $1249

Our highly skilled technicians can repair your 9905-796. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
