The 9905-708 Digital Synchronizer and Load Control for three-phase AC generators. Features 1 to 5 VDC speed bias output, Open Delta PT Configuration, 120 voltage input, with full functions.

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a 9905-708 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

9905-708

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
The 9905-708 Digital Synchronizer and Load Control for three-phase AC generators. Features 1 to 5 VDC speed bias output, Open Delta PT Configuration, 120 voltage input, with full functions.

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a 9905-708 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

9905-708 Technical Specifications

Dimensions H461mm x W265mm x D59mm
Enclosure Type Metal Chassis
Features Open Delta
Input Voltage 120VAC
Manufacturer Woodward
Model 1–5 Vdc Speed Bias
Operating Temperature –40 to +70 °C
Series DSLC 9905-708
Standards Full Upgrade Level
Storage Temperature –55 to +105 °C

Product Description

This unit is a part of the Woodward series of products, from their line of digital synchronizer and load control devices, the DSLC modules. These modules were developed and produced to control and operate several types of three-phase, alternating current generators.

The DSLC line has several advantages over other similar devices. The compact, all-in-one design reduces the amount of wiring connecting the synchronizer, load control, and automatic loading controls. The amount of functionality available within these units reduces the amount of space taken up by redundant individual modules.

The 9905-708 DSLC unit is installed with a standard Hand-Held Programmer. This reduces the calibration and installation time by allowing the user to set up the generator control prior to the system starting up. It allows operators to monitor and troubleshoot the generator’s contact switches, and input/outputs.

The 9905-708 comes with the standard operating modes. The isolated bus mode talks over the local operating network and shares proportional real and reactive loads. The utility parallel mode measures real loads on the generator and adjusts the speed control to match a set baseload.

The standard operational specifications include a temperature range that goes from -40 to 70 degrees C (-40 to 158 F). The storage temperature has a wider range, going from -55 to 105 C (-67 - 221 F).

AX Control Inc. is able to cover this unit with an unparalleled warranty. Our staff of on-site repair technicians reconditions and optimizes the hardware we have in stock.

Reviews For 9905-708
Internal Review

The load control of 9905-708 uses digital signal processing techniques to provide significantly improved accuracy and speed of response over conventional analog measurement techniques. - AX Control Tech Team

Repair Services For 9905-708

Type Lead Time Price Action
Repair Service 1-2 weeks $1473

Our highly skilled technicians can repair your 9905-708. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
