9905-360

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (2)
  • Click a star to rate this product
The 9905-360 is an obsolete DSLC part number that will function correctly with the new DSLC part numbers in all functions except dead bus closing.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 9905-360 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 9905-360
  • SKU: 9905360WO
  • Manufacturer: Woodward
  • Series: DSLC Digital Synchronizer and Load Control

9905-360

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (2)
  • Click a star to rate this product
The 9905-360 is an obsolete DSLC part number that will function correctly with the new DSLC part numbers in all functions except dead bus closing.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 9905-360 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 9905-360
  • SKU: 9905360WO
  • Manufacturer: Woodward
  • Series: DSLC Digital Synchronizer and Load Control

9905-360 Technical Specifications

Dimensions 460.65mm x 264.16mm x 58.42mm
Enclosure Type Sheet Metal
Features Humidity 95% at 38 °C
Manufacturer Woodward
Model DSLC
Operating Temperature –40 to +70 °C (-40 to 158 F)
Storage Temperature –55 to +105 °C (-67 to 221 F)
Test Method Standard US MIL-STD-810C, Method 516.2, Shock
Weight Less than 7lbs.

Product Description

Part 9905-360 is a microprocessor-based Woodward DSLC Digital Synchronizer and Load Control. This control is designed for paralleling, synchronizing, loading, and unloading three-phase generator sets when used with a Woodward speed control and an automatic voltage regulator. This control is rated for operating temps from –40 to +70 °C (-40 to 158 F) and storage temps from –55 to +105 °C (-67 to 221 F).

A few of the 9905-360 functions include:

  • Built-in diagnostics
  • Setup, metering, and diagnostic capability through a handheld programmer terminal
  • Automatic generator loading and unloading
  • Droop, baseload, and isochronous load control capability
  •  Reverse power relay.

In March 1995, Woodward DSLC part number 9905-360 was replaced by part number 9905-796. The old part number will still function properly with the new DSLC part numbers in all functions except dead bus closing. For up-to-date information on the compatibility of old DSLC part numbers or on the data format of the network variables, please contact the Woodward Technical Assistance Group.

Certain precautions to protect against static damage should be followed when working with or near the control, such as touching and holding a grounded metal object to discharge the static electricity on your body to the ground before doing maintenance on the DSLC.

Reviews For 9905-360
Internal Review

The format of the data available over the Echelon® network on the obsolete part numbers is different. The format used in the obsolete controls sends one message for each variable onto the network, while the current format sends one message for up to seven variables. - AX Control Tech

Repair Services For 9905-360

Type Lead Time Price Action
Repair Service 1-2 weeks $1190

Our highly skilled technicians can repair your 9905-360. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
