Product 9905-096 Woodward Automatic Generator Loading Control. 170-264 VAC, 50 or 60 Hz, power consumption 5 VA.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a 9905-096 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

9905-096 Technical Specifications

Chassis Metal
Dimensions 8.5inW x 7.5inH x 2inD
Features Shock Resistance 60 Gs
Input Voltage 170 and 264 V, 50 or 60 Hz
Manufacturer Woodward
Operating Temperature –40 to +185 °F
Power Consumption 5 VA
Standards UL and CSA Listed
Storage Temperature –55 to +105 °C (–67 to +221 °F)
Weight 2.25lbs

Product Description

This unit, listed here under the numerical ID, “9905-096,” is an Automatic Generator Loading control unit. This device was developed and produced by the oldest motor control manufacturer in the country, Woodward Inc. The Woodward AGLC units are designed to be used alongside a set of load sharing and speed control modules.

The 9905-096 is implemented into the generator system in order to automatically control the loading and unloading of the engine/generator set.  It is able to achieve a bumpless transfer when paralleling an engine/generator set from a load-sharing set. When the circuit breaker’s auxiliary contacts close, the 9905-096 model powers up. It compares the available potential that is on the load sharing lines of the oncoming generator with the potential of the system.

The 9905-096 model is outfitted with a Base Load setting and Unload Ramp setting. The Base Load setting causes the load to be changed at the load-ramp rate to the baseload setting. The load will then alter itself, up or down to the base-load position. The Unload Ramp setting causes the 9905-096 to ramp down at the user-selected ramp rate, whether the switch is left open or if it is closed again. These ramps can be easily adjusted, at a range from 5 seconds to 5 minutes.

AX Control Inc. is able to buy, sell, and repair the 9905-096 unit, as well as several other Woodward Inc. devices. Our inventory is comprised of items both from new, never used surplus, and as slightly used, yet completely repaired, reconditioned, and fully optimized products.

Reviews For 9905-096
Internal Review

the AGLC accomplishes a bumpless transfer when paralleling or separating an engine generator set to a load-sharing system. The 9905-096 AGLC is UL and CSA Listed. - AX technician
