Woodward Part 9903-455 AGLC Automatic Generator Loading Control. 88-132 VAC, 50 or 60 Hz input power with power consumption of 2.5 VA

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 9903-455 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

9903-455

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
Woodward Part 9903-455 AGLC Automatic Generator Loading Control. 88-132 VAC, 50 or 60 Hz input power with power consumption of 2.5 VA

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 9903-455 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

9903-455 Technical Specifications

Chassis Metal
Dimensions 8.5W x 7.5H x 2D
Features Passive Air Cooling
Input Voltage 88 to 132vac
Manufacturer Woodward
Operating Temperature -40 to +65 C
Power Consumption 2.5 VA
Vibration Standards 4 Gs between 5 and 500 Hz
Weight 2lb 4oz

Product Description

The AGLC Automatic Generator Loading Control devices are a part of the wide-ranging series of products that were manufactured, produced, and distributed by Woodward Inc. They are responsible for a large number of industrial generator modules, for both controls of the parameters needed and their regulation.

This module is listed under its numerical ID, the 9903-455. The standard applications for this AGLC unit supply generator operators with a soft load in and load out option. The loading is initiated by an auxiliary circuit breaker within the generator, while the unloading is processed when the unload contact is opened.

The 9903-455 AGLC unit is able to baseload between 1 and 15 generator sets that make up a utility. The baseload switch is either closed or jumpered, then the control automatically causes the system to ramp to the pre-set baseload level.

This unit is outfitted with a set of features that includes breaker open contacts, the ability to adjust the baseload, and a maximum load limit set into it.

The standard input power supply is a range of at least 88 to a max of 132 VAC. The total power consumption is 2.5 VA.

The environmental specifications this unit is outfitted with giving it an operational temperature range that reaches up to 85 degrees C, or 185 F, before failing to function.

Reviews For 9903-455
Internal Review

Carefully read the manual before choosing the location for the AGLC. The AGLC can have a number of control options that must be accessed by the operator. The wiring of these options may influence the selection of a location. - AX Control Tech
