8280-480 from Woodward's 723PLUS Digital Control. This unit features user-configurable communication ports, a low-voltage power supply, remote speed/load settings, and Start/Max/Turbo Boost fuel limiters.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 8280-480 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8280-480
  • SKU: 8280480WO
  • Manufacturer: Woodward
  • Series: 723 and 723PLUS Digital Control

Image Coming Soon

3 year warranty

8280-480

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
8280-480 from Woodward's 723PLUS Digital Control. This unit features user-configurable communication ports, a low-voltage power supply, remote speed/load settings, and Start/Max/Turbo Boost fuel limiters.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 8280-480 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8280-480
  • SKU: 8280480WO
  • Manufacturer: Woodward
  • Series: 723 and 723PLUS Digital Control

8280-480 Technical Specifications

Chassis Metal for Hazardous Locations
Dimensions (cm) W41.28 x L29.21 x H6.04
Input Voltage 18–40 Vdc (24 or 32 Vdc nominal)
Inrush Current (Low Voltage) 7 A for 0.1 ms
Manual 02879
Model 723Plus Analog Controller - Low Voltage, Low Speed
Power Consumption 40 W Nom.
Standards for European Union (EU) Compliant with EMC Directive 89/336/EEC (Low Voltage Model Only)
Weight 2.95kg

Product Description

There are four models of the Woodward 723PLUS Analog Load Sharing Digital Speed Control. Part 8280-480 is one of the two that are designed for engines rated at 130 rpm or less. This controller is the low voltage, low-speed model.



Because the 8280-480 is a low voltage model, it meets EMC Directive 89/336/EEC compliance, as well as ABS 2007 Steel Vessel Rules 1-1-4/7.7, 4-2-1/7.3, 4-2-1/7.5.1, 4-9-3/17, 4-9-7/13, 4-9-2/11.7 & 4-9-4/23. It is also CSA certified for Class I, Division 2, Groups A, B, C, & D. For additional compliance and listings, see 723PLUS Product Specification 03203.



The 723PLUS 8280-480 is programmed using either Watch Window PC software or a handheld programmer (Woodward part 9907-205) via a LON channel. There are additional communication channels on this controller, some of which are configurable. 723PLUS Digital Speed Control for Reciprocating Engines— Analog Load Sharing Installation and Operation Manual 02879 has more information on the communications options, including compatible Woodward accessories, such as a Modbus master device.



This controller can support magnetic pickups (MPUs) or proximity switches to accommodate a range of applications, including those with flexible couplings. Self-diagnostic tests are integrated into this control, which includes monitoring the baseline power supply, processor, and memories.

Reviews For 8280-480
Internal Review

Model 8280-480 is a Low Voltage, Low-Speed Controller suitable for any factory's hazardous environment. Reach out to our sales team via phone or email for possible replacement or repair solutions. - AX Control Techs

Repair Services For 8280-480

Type Lead Time Price Action
Repair Service 1-2 weeks $1872

Our highly skilled technicians can repair your 8280-480. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
