Woodward's Series 723PLUS Digital Controller 8280-466. Features integral load sharing/soft loading/unloading, automatic breaker opening, and 2 serial ports with Modbus and Servlink protocol choices. CSA Certified and CE Compliant.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 8280-466 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8280-466
  • SKU: 8280466WO
  • Manufacturer: Woodward
  • Series: 723 and 723PLUS Digital Control

Image Coming Soon

3 year warranty

8280-466

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (2)
  • Click a star to rate this product
Woodward's Series 723PLUS Digital Controller 8280-466. Features integral load sharing/soft loading/unloading, automatic breaker opening, and 2 serial ports with Modbus and Servlink protocol choices. CSA Certified and CE Compliant.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 8280-466 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8280-466
  • SKU: 8280466WO
  • Manufacturer: Woodward
  • Series: 723 and 723PLUS Digital Control

8280-466 Technical Specifications

Dimensions W41.28 x L29.21 x H6.04 (cm)
Features Shutdown, Alarm, Status Indicator
Input Voltage 24 or 32 Vdc nominal
Magnetic Pickup Speed 400–15 000 Hz (200–2100 rpm)
Manual Woodward 02878
Model 723PLUS Low Voltage, Low Speed
Operating Temperature -40 to +70 °C
Power Consumption 40 W nominal
Software Version -55 to +105 °C
Weight About 3kg

Product Description

Speed control model 8280-466 offers a range of customizable parameters to make it suitable for a variety of applications. This controller is part of the 723PLUS Digital Speed Control series by Woodward and is one of the few controllers in the series that is designed for low-speed engines. The 8280-466 is a low voltage speed control (18 to 40 Vdc input voltage), designed for use with reciprocating engines rated at 130 rpm or less.

The 8280-466 offers load control features and has a speed bias input to support a DSLC Digital Synchronizer and Load Control. Three other versions of this DSLC-compatible control are also available (low voltage; high voltage; and high voltage, low speed), details of which can be found in the 723PLUS Digital Speed Control for Reciprocating Engines—DSLCTM Compatible Installation and Operation Manual Product Manual 02878.

There are several discrete and analog I/Os on this controller, including two-speed signal inputs which can handle magnetic pickups or proximity switches, depending on the needs of the application. The I/Os have varying levels of configurability, the details of which can be found in manual 02878.

Parameter setting and other 8280-466 configuration and monitoring are done via either a handheld programmer (a Woodward accessory, part 9907-205) or the PC-based Watch Window software. Both of these are menu-based, keeping the process straightforward and manageable regardless of the operator’s programming experience.

Reviews For 8280-466
Internal Review

Our team of technicians has tested for verification of industry standards such as heat resistance, functional fail-safes, and voltage requirements. Contact our Sales Team by Phone or Email for lateral replacement or repair service. - AX Control Tech Teams

Repair Services For 8280-466

Type Lead Time Price Action
Repair Service 1-2 weeks $1730

Our highly skilled technicians can repair your 8280-466. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
