Single-Engine Marine Propulsion, Low Voltage/Low-Speed Model 8280-418. Woodward's 723PLUS Low Voltage Power Supplies are Rated for 18-40Vdc and are CSA Certified and CE Compliant. This Unit Features Digital References for Pressure, Speed, and Temperature.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 8280-418 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8280-418
  • SKU: 8280418WO
  • Manufacturer: Woodward
  • Series: 723 and 723PLUS Digital Control

Image Coming Soon

3 year warranty

8280-418

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
Single-Engine Marine Propulsion, Low Voltage/Low-Speed Model 8280-418. Woodward's 723PLUS Low Voltage Power Supplies are Rated for 18-40Vdc and are CSA Certified and CE Compliant. This Unit Features Digital References for Pressure, Speed, and Temperature.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 8280-418 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8280-418
  • SKU: 8280418WO
  • Manufacturer: Woodward
  • Series: 723 and 723PLUS Digital Control

8280-418 Technical Specifications

Dimensions (in) 16.25W x 11.5L x 2.375H
Enclosure Type Metal for Hazardous Locations
Manufacturer Woodward
Model Single engine marine propulsion, low voltage/low speed
Operating Temperature -40 to +70 °C (-40 to +158 °F)
Series 723PLUS Control/Marine
Storage Temperature -55 to +105 °C (-67 to +221 °F)
Weight 6.5lbs before packaging

Product Description

Part 8280-418 is a single-engine marine control in the Woodward 723PLUS series. There are several similar 723PLUS controls, this one is for single-engine, single-propeller (variable or fixed pitch) propulsion systems. It is a low-voltage, low-speed model. The 8280-418 is designed for use with low-speed diesel reciprocating engines and has a power supply that is rated for 18-40 Vdc. For the medium- and high-speed versions of this control, see model number 8280-419.



This Woodward 723PLUS control can be used with either magnetic pickups (MPUs) or proximity switches, so it can be used in applications with flexible couplings. There are two inputs that both support either speed sensing option. The 8280-418 also has inputs for remote speed reference, lube oil pressure, water pressure, and air manifold pressure.



The 8280-418 has three communication ports. One of these ports can be used to interface to Watch Window (PC-based software) or a handheld programmer, while the other ports can be configured for RS-232, RS-422, or RS-485 communications. Watch Window and the handheld programmer are both Woodward accessories. Another optional PC-based interface that can be used with the 8280-418, is the 723PLUS Marine SEP Control View software. Woodward 723PLUS Product Manual 02880 has more information on all these options.



The Woodward 8280-418 control is CSA Certified and CE Compliant. It also complies with EN50081-2 and EN50082-2 requirements provided it is put into service per the instructions outlined in the product manual.

Reviews For 8280-418
Internal Review

Model Number 8280-418 can be used in conjunction with Single-engine marine propulsion systems that require low voltage and low speed. Please refer to unit-specific installation manuals provided on our site, or reach out to us via email with any remaining questions. - AX Control

Repair Services For 8280-418

Type Lead Time Price Action
Repair Service 1-2 weeks $1892

Our highly skilled technicians can repair your 8280-418. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
