8280-417

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (1)
  • Click a star to rate this product
The Digital Controller 8280-465 can be programmed to suit applications for torsional filtering requiring two MPUs or proximity switches. The controller can be used in load-sharing systems as it contains proper circuitry and connections. The unit also includes four analog inputs, three analog outputs, eight discrete inputs, and three discrete outputs.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 8280-417 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8280-417
  • SKU: 8280417WO
  • Manufacturer: Woodward
  • Series: 723 and 723PLUS Digital Control

Image Coming Soon

3 year warranty

8280-417

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (1)
  • Click a star to rate this product
The Digital Controller 8280-465 can be programmed to suit applications for torsional filtering requiring two MPUs or proximity switches. The controller can be used in load-sharing systems as it contains proper circuitry and connections. The unit also includes four analog inputs, three analog outputs, eight discrete inputs, and three discrete outputs.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 8280-417 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8280-417
  • SKU: 8280417WO
  • Manufacturer: Woodward
  • Series: 723 and 723PLUS Digital Control

8280-417 Technical Specifications

Chassis Metal
Dimensions W41.275 x L29.21 x H6.0325
Input Voltage 90–150 Vdc (125 Vdc nominal)
Inrush Current (high voltage) 22 A for 15 ms
Manual 02831
Model 8280-417 723PLUS with high-voltage power supply
Standards Mechanical Vibration Lloyd’s Register of Shipping Specification Vibration Test 1
Weight Less than 3kg

Product Description

Part 8280-417 is one of two DSLC/MSLC Gateway Controls in the Woodward 723PLUS series. This unit has a high voltage power supply, with a 90–150 Vdc (125 Vdc nominal) input voltage. A low-voltage version of this control is also available (model 8280-416).



Designed for load sharing control and generator system load management, the 8280-417 DSLC/MSLC Gateway Control can connect with up to fourteen DSLC units and one MSLC unit to extract generator information via a LON network. The 8280-417 can interface to a human/machine interface (HMI), or other Modbus master device, through two serial channels. A third port allows network-connected MSLC and DSLC units to receive commands and values, including forced commands and values if necessary for testing purposes.



When the 8280-417 control is put into service per the instructions in Woodward 723PLUS Digital DSLC/MSLC Gateway Installation and Operation Product Manual 02831, it complies with EN50081-2 and EN50082-2 requirements. This control is also CSA certified for Class I, Division 2, Groups A, B, C, & D. Additional compliance and listing information can be found in 723PLUS manual 03203.



The 8280-417 control’s Installation and Operation Manual also contains details on the Woodward 723PLUS accessories. This includes a handheld programmer for adjusting the control parameters, Servlink/ Watch Window PC interface for monitoring and editing control variables in real-time and an MSLC and DSLC system for generator system management.

Reviews For 8280-417
Internal Review

Part number 8280-417 (Ctrl Assm 9906-619) is a durable Digital Controller from Woodward's 723PLUS Series that fully protects its PCB with a metal chassis. Note that the unit can withstand temperatures up to 70 C/158 F, but anything over that will result in reduced lifespans. - AX Control Team of Technicians

Repair Services For 8280-417

Type Lead Time Price Action
Repair Service 1-2 weeks $1829

Our highly skilled technicians can repair your 8280-417. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
