8280-339

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
The Digital Controller 8280-339 is programmable to suit applications requiring two MPUs or proximity switches. The unit also includes four analog inputs, three analog outputs, eight discrete inputs, and three discrete outputs. Control Assembly Model Number 9906-619.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

3 Year Warranty: Learn More
Sell Surplus: Have a 8280-339 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8280-339
  • SKU: 8280339WO
  • Manufacturer: Woodward
  • Series: 723 and 723PLUS Digital Control

8280-339

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
The Digital Controller 8280-339 is programmable to suit applications requiring two MPUs or proximity switches. The unit also includes four analog inputs, three analog outputs, eight discrete inputs, and three discrete outputs. Control Assembly Model Number 9906-619.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

3 Year Warranty: Learn More
Sell Surplus: Have a 8280-339 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8280-339
  • SKU: 8280339WO
  • Manufacturer: Woodward
  • Series: 723 and 723PLUS Digital Control

8280-339 Technical Specifications

Chassis W41.275 cm x L29.21 cm x H6.0325 cm
Features 22 LEDs
Input Voltage 18-40Vdc 40W Supply Input
Manufacturer Woodward 723PLUS
Model Ctrl Assm 9906-619
Storage Temperature –67 to +221 °F
Weight Less than 7 lbs.

Product Description

For applications requiring magnetic pickups (MPUs) or proximity switches, part 8280-339 provides the flexibility of working with either option. For steady-state speed control, the minimum frequency is 30 Hz, though the speed input frequency range does differ between the two-speed sensing methods. The range for MPU is 400 Hz to 15 kHz, while the range for proximity switch is 30 Hz to 15 kHz.



The 8280-339 has several configurable analogs and discrete I/Os. This includes eight discrete inputs, four analog inputs, three discrete outputs, and three analog outputs. The analog I/Os have an accuracy rating of 0.5% of full scale, and a load-sharing input boasts 1.0% of full-scale accuracy. The eight discrete inputs on this controller have a 10 ms ±15% response time.



There are several accessories that can be used with the 8280-339 controller, including Woodward’s Hand Held Programmer (part 9907-205). It’s through this programmer (connected to one of the unit’s serial ports) that the I/Os and set points are configured. The programmer is a menu-driven system, so managing the controller is straightforward even for users without much programming knowledge.



Woodward 723PLUS model 8280-339 is CE Compliant and is CSA Certified for Class I, Division 2, Groups A, B, C, and D (CSA Certificate 2244634).

Reviews For 8280-339
Internal Review

Model 8280-339 is a durable controller suitable for any factory's hazardous environment. We have tested in-stock units for functionality and our surplus of availability makes a direct replacement a breeze. Reach out to our sales team via phone or email for any inquiries. - AX Control Tech Team

Repair Services For 8280-339

Type Lead Time Price Action
Repair Service 1-2 weeks $1657

Our highly skilled technicians can repair your 8280-339. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
