Woodward's Series 723PLUS Digital Controller Model 8280-1001. Ctrl Assm 9906-619. Features integral load sharing and soft loading and unloading, automatic breaker opening, compatible with DSLC Digital Synchronizer and Load Control.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

3 Year Warranty: Learn More
Sell Surplus: Have a 8280-1001 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8280-1001
  • SKU: 82801001WO
  • Manufacturer: Woodward
  • Series: 723 and 723PLUS Digital Control

8280-1001

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.67 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.67 (3)
  • Click a star to rate this product
Woodward's Series 723PLUS Digital Controller Model 8280-1001. Ctrl Assm 9906-619. Features integral load sharing and soft loading and unloading, automatic breaker opening, compatible with DSLC Digital Synchronizer and Load Control.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

3 Year Warranty: Learn More
Sell Surplus: Have a 8280-1001 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8280-1001
  • SKU: 82801001WO
  • Manufacturer: Woodward
  • Series: 723 and 723PLUS Digital Control

8280-1001 Technical Specifications

Chassis Metal for Hazardous Locations
Dimensions 16.25W in x 11.5L in x 2.375H in
Input Voltage 18-40 Vdc, 40 W
Model Ctrl Assm 9906-619
Operating Temperature MAX 70C
Power Consumption 40 W nominal
Series 723PLUS
Weight 6lbs 8oz

Product Description

Woodward part number 8280-1001 is a 723PLUS Digital Control that has two-speed inputs. These inputs can be used for either magnetic pickups (MPUs) or proximity switches, making this control suitable for various applications, including load-sharing systems and applications with torsional filtering. Woodward 723PLUS controls such as this one consist of a single printed circuit board housed in a sheet-metal chassis.

Part 8280-1001 has analog and discrete inputs and outputs. These I/Os are in addition to the two-speed inputs and include:

  • Three analog outputs
  • Four analog inputs
  • Three discrete outputs
  • Eight discrete inputs

Both analog and discrete I/Os are configurable, making the 8280-1001 a customizable control.

There are several accessories to the 723PLUS Digital Controls. Part 9907-205, Woodward’s Hand Held Programmer, plugs into one of the serial ports on this unit and is used to adjust the 8280-1001 control. Watch Window Software (part number 8923-932) may also make adjustments via PC. 723PLUS Manual 02877 has additional details on accessories compatible with part 8280-1001.

This digital control is CSA Certified for Class I, Division 2, Groups A, B, C, & D, and is Compliant with EMC Directive 2004/108/EC and Low Voltage Directive 2006/95/EC. 723PLUS Digital Control Product Specification 02876 has full details on compliance and listings of Woodward part 8280-1001.

Reviews For 8280-1001
Internal Review

8280-1001 units are CE Marked and UL listed and support UL hazardous locations Class I div 2 Groups A/B/C/D. These certifications guarantee your unit to be able to stand up to industry standards and supply you with longevity for you and your systems. - AX Control Tech Team

Repair Services For 8280-1001

Type Lead Time Price Action
Repair Service 1-2 weeks $1880

Our highly skilled technicians can repair your 8280-1001. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
