The 8200-1312 Marine/ATEX Compliance LVDC Governor made for Woodward's 505XT Digital Governor Series

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a 8200-1312 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: 8200-1312
SKU: WO-59496

Manufacturer: Woodward
Series: 505XT Digital Governor

Description
Repairs
Warranty
Manuals

8200-1312 Technical Specifications

Part Number	8200-1312
Functional Description	Marine/ATEX Compliance LVDC Governor
Manufacturer	Woodward
Series	505XT Digital Governor
Ethernet 10/100 communication ports	4 Isolated Ports
CAN communication ports	4 Isolated Ports
Operating/Storage Temperature	–30 °C to +70 °C
NEMA Rating	IP20
Overvoltage Category	2
Pollution Degree	2
Clock Battery	Real-Time

About the 8200-1312

The 8200-1312 Marine/ATEX Compliance LVDC Governor made for Woodward's 505XT Digital Governor Series has a number of inputs and outputs that it interacts with during normal fault-free operation. Some of these I/Os include:

Speed Control Inputs
Analog 4-20 mA Control Inputs
Discrete Contact Inputs
Actuator Control Outputs
Analog 4-20 mA Control Outputs
Relay Outputs

A number of additional optional I/Os exist for this 8200-1312 Digital Governor, including the 8200-1203, 8200-1200, 8200-1204, and 8200-1205 options.

8200-1203 CAN Ports

A number of CAN Ports intended for standard communications have also been included in the 8200-1312 Governor Module's assembly. These are the:

CAN #1 Link to digital drivers/actuators Port
CAN #2 Link to LinkNet distributed I/O nodes Port
CAN #3 Link to Power management products Port
CAN #4 Reserved Port

The CAN #3 Link to Power management products Port has compatibility with Woodward products such as LS-5 and the MFR300.

Frequently Asked Questions about 8200-1312

Can the 8200-1312 Governor's screen brightness be changed?

Yes. In fact, a pushbutton with a sun symbol on its is responisble for altering the 8200-1312's brightness parameters.

Does this governor feature any RS-232 ports?

Yes. One RS-485 RS-232 port and one Service RS-232 port are included in the assembly of the 8200-1312 Digital Governor.

Reviews For 8200-1312

Internal Review

(5.0)

This 8200-1312 controller/governor supports expanded I/Os when using Woodward CAN distributed I/O nodes that are bought separately. Two speed sensor inputs exist for this 8200-1312 module. It also has eight total relay outputs specifically classified as form-C relay outputs. - AX Control Lead Technician
