Home Woodward 505XT Digital Governor 8200-1310

❮

❯

About | Product Specifications | FAQs

8200-1310

Q: What processes is the 8200-1310 designed to handle?

The 505XT Series&#39; 8200-1310 was built for functions such as extraction, extraction/admission, or admission steam turbine control.

5.00 (1)
Click a star to rate this product

5.00 (1)
Click a star to rate this product

The 8200-1310 Standard Compliance LVDC Digital Governor made for Woodward's 505XT Series

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a 8200-1310 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: 8200-1310
SKU: WO-59494

Manufacturer: Woodward
Series: 505XT Digital Governor

Description
Repairs
Warranty
Manuals

8200-1310 Technical Specifications

Manufacturer	Woodward
Series	505XT Digital Governor
Part Number	8200-1310
Functional Description	Standard Compliance LVDC Digital Governor
Display Type	8.4” LCD
Ethernet Ports	4 Isolated 10/100 Communication Ports
CAP Configurable Update Rates	5 ms to 160 ms
Speed Sensor Inputs	2 Inputs
Operating Temperature	–30 °C to +70 °C
Storage Temperature	–30 °C to +70 °C

About the 8200-1310

The 8200-1310 Standard Compliance Digital Governor comes with a host of functional hardware features and applications. Some of these listed in original Woodward manual materials include:

Critical speed avoidance
Auto start sequencing
Zero speed detection
Peak speed indication
Direction of rotation
Feed-forward loop for compressor units

The 8200-1310 Governor's critical speed avoidance has 3 speed bands. Load droop and isochronous loads can be shared between 8200 Governors through use of the DSLC-2 control.

8200-1310 Modes of Operation

The 8200-1310 Digital Governor has three total modes of operation:

Configuration Mode - A customization-focused mode that will trigger an IO LOCK state for safety purposes
Calibration Mode - A secondary customization mode focused on the altering of basic parameters during a complete shut-down
Operation Mode - The mode representing a normal functioning 8200-1310 status

Please note that the 8200-1310 Governor's configuration mode does require a password for access given its inherent security risk.

Frequently Asked Questions about 8200-1310

Can this 8200-1310 Governor interface with a Ext/Adm turbine?

Yes. This 8200-1310 Digital Governor is considered compatible with Ext/Adm turbines possessing split range inlet arrangements.

What processes is the 8200-1310 designed to handle?

The 505XT Series' 8200-1310 was built for functions such as extraction, extraction/admission, or admission steam turbine control.

Reviews For 8200-1310

Internal Review

(5.0)

Seven total PID controllers are critical to the overall functionality of this 8200-1310 Digital Governor. So too is its ability to automatic optimization tune its dynamic gains. The 8200-1310 service menu can be accessed in a powered down mode. - AX Control Lead Technician
