Woodward Part 8273-505 2301D-EC Digital Load Sharing and Speed Control. 24 VDC input, with Modbus, rated for ordinary locations.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 8273-505 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

8273-505

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.80 (4)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.80 (4)
  • Click a star to rate this product
Woodward Part 8273-505 2301D-EC Digital Load Sharing and Speed Control. 24 VDC input, with Modbus, rated for ordinary locations.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 8273-505 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

8273-505 Technical Specifications

Actuator Current Range 0–20 mA, 4–20 mA, 0–200 mA
Enclosure Ordinary Locations
Humidity 95% at +68 to +131 °F condensing
Input Voltage 24VDC
Manufacturer Woodward
Operating Temperature –40 to +158 °F
Port RS-232 and RS-422 with Modbus Protocol
Series 2301D-EC DLS & SC

Product Description

This module 8273-505 is one of the several Woodward-manufactured products that is classified as a Woodward 2301D-EC Digital Load Sharing and Speed Control module, intended for engine management, regulation, and control.

The 8273-505 module is designed to control the load sharing and speed of diesel or gas-powered engines. This unit, as well as the others in the Woodward 2301D-EC category, are based around a microprocessor design. This increases the amount of flexibility in the unit’s control software.

The 8273-505 is housed within a protective sheet metal chassis, and the internal components to run the software consist of a single printed circuit board. There are three operating modes provided to run the functionalities of this unit.

The isochronous mode is intended for use with constant engine speed with either a single engine or two or more that are controlled by a Woodward analog load sharing control system on an isolated bus. The droop mode is used for speed control for a single-engine on an infinite bus, or a parallel operation of two or more engines. The baseload mode is able to provide a constant load level operation against a bus with the controlled load. The load setting is set by a fixed reference, external analog input, or contact control.

Reviews For 8273-505
Internal Review

The engine, turbine, or another type of prime mover should be equipped with an Overspeed shutdown device to protect against runaway or damage to the prime mover with possible personal injury, loss of life, or property damage. - AX Control Tech
