Woodward part 9907-015 series 2301A Load Sharing and Speed Control. Equipped with load-sharing line relay, high/low voltage, and reverse/forward acting.

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 9907-015 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Image Coming Soon






9907-015

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
Woodward part 9907-015 series 2301A Load Sharing and Speed Control. Equipped with load-sharing line relay, high/low voltage, and reverse/forward acting.

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 9907-015 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

9907-015 Technical Specifications

Actuator Compensation time constant compatibility 0-500 ms
Droop Input external switch, open terminals 14-16
Idle Speed Select Input external switch, open terminals 19-16
Load Sharing Input 0-6 Vdc
Low Idle Speed 55% rated
Power Supply Rating 90-150 Vdc/85-132 Vac OR 20-40 Vdc

Product Description

The control unit 907-015 is manufactured by Woodward Inc and is from the 2301A Load Sharing and Speed Control series. AX Controls supplies this control in our surplus of new and secondhand inventory. The 9907-015 control comes in a high-voltage or low-voltage model, as well as a forward-acting or reverse-acting control unit.

When preparing to install your control make sure it is being installed in an area where there will be limited exposure to condensation and as well as in an area that has limited exposure to potential water damage. The control being installed in an area where condensation and potential water damage will occur poses a risk to the operation of the control, if the control obtains water damage it will hinder the performance of the control.

This control is equipped with a load-sharing-line relay that is located within the control, meaning that a relay is not necessary between the load-sharing-line bus and the control. If using different control to load share you should not connect the shield at any points in which connections to the load-sharing-line bus are made. Be sure that when connecting the control no other cables are used except for those that are shielded using a different type of cable to install this device could cause interference during operation.

The 9907-015 control can be purchased through AX Control, we also offer repair to this control, if your control requires repair inquiries into the cost of repair can be made by phone or email. We also offer a one to a three-year warranty on all models as well as models that undergo repairs.

Reviews For 9907-015
Internal Review

Only use shielded wiring and cables when you are connecting your control and engine, if you use any other wires then it will impede the proper function of your control. Read your manual before use to guarantee no errors during operation. - AX Control Tech Team
