Woodward part 9905-194 series 2301A Load Sharing and Speed Control. Can be used with more than two prime movers, the load gain potentiometer sits at six volts.

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 9905-194 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Image Coming Soon






9905-194

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
Woodward part 9905-194 series 2301A Load Sharing and Speed Control. Can be used with more than two prime movers, the load gain potentiometer sits at six volts.

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 9905-194 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

9905-194 Technical Specifications

Actuator Compensation time constant compatibility 0-500 ms
Engine Operation Steam/Gas Turbines
Power Consumption </= 15 W
Speed Control Range 500-1500 Hz, 1000-3000 Hz, 2000-6000 Hz, 4000-12000 Hz
Standards CSA Certified
Synchronizer ±5 Vdc for speed change

Product Description

Control model 9905-194 from the Load Sharing and Speed control by Woodward for the 2301A series is a forward-acting, low voltage model. The actuator current on the control operates at 0-20 mA and has a speed set input of 4-20 mA. With twenty-nine terminals for connection between load-sharing lines, minimum-fuel contact, speed trim or jumper, and many other contacts can be connected through the terminal.

Before starting up your control and prime mover adjust the potentiometers on your control, the load gain on your control should be set in the range of mid-position. To adjust the load gain on your control have the generator that the control is attached to has to run isochronously and not paralleled, crank up the prime mover and apply the full load, then measure the voltage of the load signal and alter the potentiometer of the load gain for six volts.

The speed control system you are using to attach to your prime mover is made up of five parts; one of those is a frequency to voltage converter, the purpose of this device is to convert the ac signal from the speed sensor through the control and changes it to a correlative dc voltage.

Reviews For 9905-194
Internal Review

To ensure peak performance of your control use your control with a power supply that is accurate to use with a low-voltage model, using anything other than a power supply that works well with a low-voltage model will possibly cause errors. Check your manual to ensure the power supply you are using is correct. -AX Control Tech Team

Repair Services For 9905-194

Type Lead Time Price Action
Repair Service 1-2 weeks $1039

Our highly skilled technicians can repair your 9905-194. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
