Woodward part 9905-145 series 2301A Load Sharing and Speed Control. Load gain of 6 Vdc maximum at 5 A CT current, MPU clearance of 0.010-0.040 inches

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 9905-145 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Image Coming Soon






9905-145

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
Woodward part 9905-145 series 2301A Load Sharing and Speed Control. Load gain of 6 Vdc maximum at 5 A CT current, MPU clearance of 0.010-0.040 inches

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 9905-145 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

9905-145 Technical Specifications

Manufacturer Woodward
MPU Clearance 0.010-0.040 inches
Operating Temperature –40 to +185 °F
Power Consumption </= 15 W
Speed Sensor MPU min 1.0 Vac to max 30 Vac
Weight < 4 lbs

Product Description

The Woodward 2301A Load Sharing and Speed Control series with control 9905-145 is available for sale at AX Control, where we also buy, repair, and refurbish the device as well. The 9905-145 is available in high-voltage or low-voltage models, if the model you have purchased is a high voltage model it will be indicated on the front of the sheet metal frame of the control whereas if a low voltage model it will not be indicated on the front of the control.  Be advised that the power supply ratings for the models are different, the high voltage model can be operated with a Vac range of 88-132 while the low voltage model cannot be used with a Vac power supply at all.

Assess all terminals, screws, and the sheet metal frame to ensure that there is no damage, damage to any of these will hinder the function of the control and may cause malfunctions when operating it with an engine. The potentiometers will not be set when you receive the control and must be set by the operator.

While assessing and unpacking your control check the speed sensor for damage, and make sure that there is proper clearance between the sensor and gear if the sensor is an MPU (magnetic pickup), the clearance between the two should be at 0.010 to 0.040 inches.

AX Control offers repair services for your control, if repair is needed we offer a warranty of one to three years. We can be contacted by phone number at (919) 372-8413 or by email at sales@axcontrol.com

Reviews For 9905-145
Internal Review

Check the power supply rating that you need to use with your model; if using a different power supply than what is intended for use with this control will cause the function to be inhibited. - AX Control Tech Team
