9905-136

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
Woodward part 9905-136 series 2301A Load Sharing and Speed Control. Can be used with MPU, and required use with twisted conductor shield cable.

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 9905-136 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Image Coming Soon






9905-136

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
Woodward part 9905-136 series 2301A Load Sharing and Speed Control. Can be used with MPU, and required use with twisted conductor shield cable.

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 9905-136 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

9905-136 Technical Specifications

Acceleration Ramp 0-10 s, switch activated, close terminals 19-16
Cables Shielded Twisted Pairings
Power Supply Rating 90-150 Vdc or 85-132 Vac for high voltage models.
Standards CSA Certified
Vibration 4 Gs or 5-500 Hz

Product Description

Control model 9905-136 designed for Woodward’s 2301A series is a control available for sale or repair from AX Control inc, this specific model is available in high-voltage or low-voltage. The installation of the control requires the control and prime mover to be connected by shielded wiring if for any reason the control needs to be installed with extreme electromagnetic interference, double-shielded wire, and shielded wire run in conduit or other safeguards should be taken into account.

Using shielding wiring requires the shield to undergo special accommodation so the shield can be connected to the control; the outer insulation of the shield must be removed from both ends take extreme caution to not cut the braided shield, use a pointed edge tool, and begin to cautiously spread the strands of the shield, once the strands have been spread carefully pull the inductors from the shield as the shield is braided carefully twist to be sure that the shield does not fray, remove at least a fourth of an inch of insulation from the inner conductor, once these steps have been taken connect the wiring and shield to the proper terminals.

Take caution when operating the control and prime mover together as errors could occur, one of the errors that can occur is overspeeding of the prime mover, if this occurs check the magnetic pickup that has been attached to the control as well as the 9905-136 control itself. While checking the magnetic pickup if you notice that the output voltage on the magnetic pickup is at speeds above the idle of at least 1.0 Vrms if the magnetic pickup has failed and the override failed speed signal circuit has deactivated then the 9905-136 will go into maximum fuel.

Reviews For 9905-136
Internal Review

This control performs at an exceptional rate. The acceleration ramp on this model performs at a rate of 0-10 seconds when the ramp has been activated. Check the manual for proper installation of the model. - AX Control Tech Team

Repair Services For 9905-136

Type Lead Time Price Action
Repair Service 1-2 weeks $1315

Our highly skilled technicians can repair your 9905-136. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
