Woodward part 9903-327 series 2301A Load Sharing and Speed Control. Accessible in reverse/forward acting controls, actuator output 7.5 Vdc max.

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 9903-327 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Image Coming Soon






9903-327

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (1)
  • Click a star to rate this product
Woodward part 9903-327 series 2301A Load Sharing and Speed Control. Accessible in reverse/forward acting controls, actuator output 7.5 Vdc max.

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 9903-327 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

9903-327 Technical Specifications

Low Idle Speed 55% rated
Manual Online
Manufacturer Woodward
Operating Temperature -40 to 85 C
Power Consumption </= to 15 W nominal
Standards CSA Certified
Synchronizer ±5 Vdc for speed change with Woodward SPM-A synchronizer
Weight 3.87 lb

Product Description

Woodward INCs 2301A Load and Sharing Control unit 9903-327 is a control that can be set up with another control in the same series that when connected together uses the minimum fuel amount to control and power the unit that the 9903-327 has been connected to. This control is accessible in reverse-acting and forward-acting units for use with individual or dual actuators. This control is available in several voltage models, high-voltage or low-voltage, and must be used with a power supply that contains a minimum of 15 W.

When it comes to the speed and phase matching (SPM) synchronizer, the control needs to be linked by shielded wires, and stability throughout the synchronizer needs to be throughout the entirety of the synchronizer; the synchronizer and shield must not be directly connected. Peak performance is not always possible with the gain potentiometer at the highest clockwise setting; sometimes the potentiometer must be diminished in the slightest to secure stability under many different conditions.

This control contains twenty-nine terminals, terminals twenty and twenty-one connect the unit and the actuator, when connection the actuator and the control the positive lead must be connected to terminal twenty, and the negative terminal must be connected to terminal twenty-one; terminals twenty-five and twenty-six connect the SPM and the unit. The shield of the wires need not have an exposure of wire that is 50 mm or longer, having the exposed wire can lead to the unit not running properly.

A.X Control inc provides a three-year warranty on this 9903-327 control and is well equipped to buy, resell and repair this unit for your convenience.

Reviews For 9903-327
Internal Review

A speed sensor is offered with the control but be sure that you are prepared to do an emergency shutdown as the speed sensor will not do that itself. - AX Control Tech
