Woodward 9900-432 series 2301A Load Sharing and Speed Control. A single circuit board housed in a metal frame, 50/60 Hz power source, and 90-150 VDC.

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 9900-432 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Image Coming Soon






9900-432

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
Woodward 9900-432 series 2301A Load Sharing and Speed Control. A single circuit board housed in a metal frame, 50/60 Hz power source, and 90-150 VDC.

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 9900-432 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

9900-432 Technical Specifications

Droop External Switch, Open Terminals 14-16
Idle Speed Select External Switch, Open Terminals 19-16
Load Sharing 0-6 Vdc
Manufacturer Woodward
Operating Temperature -40 - 85 C/ -40 - 185 F
Power Consumption </= to 15 W nominal
Standards CSA Certified
Vibration Endurance 4 Gs, 5 to 500 Hz

Product Description

Woodward’s 9900-432 control is a forward-acting 110 V control unit. The 2301 A control unit consists of a single circuit board housed in a sheet-metal frame; everything that is needed to be accessed to control the unit is accessible through the front of the frame. If voltage is lost when using this control the actuator will call for the actuator to use minimal fuel. The power of the control needs to be given from a  VDC unit that is 90-150 or a VAC unit of 88-132 or a 50/60 Hz source.

Minimum fuel contact is designed as an alternative to a typical shutdown of the prime mover. Before the prime mover is started the speed signal of the control is absent. In prime movers that have cranking motors, the speed associated with cranking the mover is satisfactory to provide the signal meaning that overrides contact is not needed for starting. When the minimum fuel contact is not used a jumper must be connected between specifically terminal 17 and terminal 16 on low-voltage models; and between terminal 17 and terminal 0 on high-voltage models, the control will not function if the 24 VDC is not connected to terminal 17.

The external speed trim on the 9900-432 control must be connected to terminal 23 and terminal 24 by way of a jumper unless the alternate method of remote speed trim potentiometer is being used. The wiring of the control must be made of shielded cable with twisted conductor pairings, these signal lines must be shielded to avoid picking up other signals from nearby equipment.

Reviews For 9900-432
Internal Review

The cables that are installed when connecting the control must be shielded, do not attempt to solder the cable yourself. Attempting to solder the cable yourself will result in serious injury. - AX Control Tech Team
