About the LS-5016
The LS-5016 Flanged-Base Air Flow Filter made for Warren's LS and FS Electro-Mechanical Flow Sensors Series has a number of unique advantages specifically as an LS Series air flow switch. Some of these include its:
- MIL shock/vibration/ambient standards certification
- -55°C low minimum operation temperature
- Enhanced MTBF rate
- Self contained switch
- Built in time delay
- Transient flow loss ignorance
The LS-5016 is generally considered resistant to air temperatures.
LS-5016 Specifications
The LS-5016 comes with a number of critical operation and hardware specifications stored in chart form just below:
| Heater Voltages |
5V., 12V., 28V.,115V AC/DC |
| Input Power |
4 W Nominal |
| 2A Contact Rating |
resistive up to 115V AC |
| 1A Contact Rating |
resistive up to 32V DC |
| Usable Voltage Rate |
±10% of nominal |
| Energized Temperature Range |
-55°C to +85°C |
