Is the FS-3102 UL listed?

Yes. This FS-3102 is a UL-recognized sensor component.

How many pins feature on the FS-3102 Switch?

The FS-3102 unit is a nine-pin sensor/switch that was designed for socket mounting.

DS200AAHA1	GE Turbine Control	Mark V

DS200AAHA1	GE Turbine Control	Mark V

Home Warren LS and FS Electro-Mechanical Flow Sensors FS-3102

❮

❯

About | Product Specifications | FAQs

FS-3102

5.00 (1)
Click a star to rate this product

5.00 (1)
Click a star to rate this product

The FS-3102 Air Flow Sensing Switch made for Warren G-V's LS and FS Electro-Mechanical Flow Sensors Series

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a FS-3102 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: FS-3102
SKU: WA-59491

Manufacturer: Warren
Series: LS and FS Electro-Mechanical Flow Sensors

Description
Repairs
Warranty
Manuals

FS-3102 Technical Specifications

Part Number	FS-3102
Functional Description	Air Flow Sensing Switch
Series	LS and FS Electro-Mechanical Flow Sensors
Manufacturer	Warren
Heater Voltage	5V., 12V., 24V., or 115V. AC/DC
Input Power	2.5 Watts
2A Contact Rating	Resistive up to 115V. AC
1A Contact Rating	Resistive up to 32V. DC
Response Time	1 to 20 seconds @ rated voltage
Temp Range	0°C to 85°C
Air Flow	250 LFPM

About the FS-3102

The FS-3102 Air Flow Sensing Switch made for Warren G-V's LS and FS Electro-Mechanical Flow Sensors Series has a consistent set of intended product applications. These would include in:

Fire control systems
MIL radar or communications systems
Computer or peripheral computer systems
Shipboard ventilation or exhaust systems
Weapons systems

The FS-3102 Switch here is able to function across this wide array of possible applications due to its extreme environmental ratings including a minimum operating temperature of negative fifty-five degrees celsius.

FS-3102 Benefits

A number of benefits exist specifically for this FS-3102 model, as outlined in the documentation linked above. Some of these benefits include its:

Self contained sensor/switch
No need for additional circuitry
Socket-based mounting
115V heater voltage
Minimum airflow interference

Reviews For FS-3102

Internal Review

(5.0)

This FS-3102 airflow switch is not sensitive to air temperature, likely as a result of its socket-base mounting. The FS-3102 Airflow Switch has the N.C. contact configuration S.P.S.T. rating. In addition to this, the FS-3102 Switch is built around a heated thermistor. - AX Control Lead Technician
