15-Inch Human-Machine Interface XGA Touchscreen Model G15C0000 from Red Lion Graphite HMI is a 15" Display configured with their Crimson Software. Updates are available through Red Lion. Designed for Indoor use only, the enclosure is rated for Type 4X Indoor/IP66 (Face) and IP20 (Rear).



Sell Surplus: Have a G15C0000 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: G15C0000
  • SKU: G15C0000RL
  • Manufacturer: Red Lion
  • Series: Graphite HMIs

G15C0000 Technical Specifications

Part Number G15C0000
Series Graphite HMIs
Manufacturer Red Lion
Faceplate Dimensions Inches (mm) W14.03" (356.3) x H11.10" (281.8)
Weight 7.73 lb. (3.5 Kg)
Required Power Supply Rating 10-30 VDC
Expansion Slots 3 Serial Ports + 1 SD + 8 Module Slots
Certifications and Compliances CE, ATEX, IECEx Approved, UL Listed, UL Hazardous, ABS
Shock Resistance to IEC 68-2-27 Operational 40 g (10 g, modules w/relays)
Vibration Resistance to IEC 68-2-6 Operational 5-500 Hz, 4 g

Product Description

Produced by Red Lion as part of their Graphite HMI series, the G15C0000 model is a 15-inch display touchscreen with XGA color technology with an approximate resolution of 1024 x 768 pixels. This model is equipped with OPC UA historical access and an OPC UA client driver. This interface also has eight module slots, which include a USB B port and an Ethernet port, two RS232 ports, an RS485 port, a power connector, an optical auxiliary Ethernet, and an optional auxiliary RS485 comms port.

When the G15C0000 model is used, it will operate on a power supply of 28 VDC but includes a lithium BR2032 battery to keep time when the module does not have power. The battery within the HMI will not affect any of the memory already on the interface; all data and configuration sets are stored in the non-volatile memory. There are 256 Mbytes of non-volatile Flash memory available on this model with a memory card that will accept the standard capacity card adding additional memory.

This model will be mounted to a panel using a chassis mount. Please note that when mounting the G15C0000 model, it is always mounted in a location indoors as it is only rated to be used indoors; using the model outdoors could cause issues and inhibit the user from using the G15C0000 model as it should be used. For more information on mounting procedures and why this module must be used indoors, refer to the G15-H Bulletin from Red Lion to ensure all procedures are being followed.

Frequently Asked Questions about G15C0000

What does the G15C0000 terminal do?

The function of the G15C0000 HMI is to synchronously communicate with several types of hardware through the 10 Base T/100 Base-TX Ethernet communications and high-speed RS-232/485 serial communication ports.

What is the G15C0000 model made of?

The G15C0000 model is made up of a cast aluminum NEMA 4X-IP66 enclosure rating. This model can only be used in indoor applications when it is correctly fitted with the correct gaskets. It should be noted that the model has only been evaluated by Red Lion for low risk of mechanical impacts.

What procedures must be followed when mounting this unit?

When mounting this module, one of the procedures that must be followed is complying with articles 500 and 502 of the NEC by mounting the module in a dust-tight end-enclosure with the face of the display exposed. This model must also be wired using Division 2 wiring methods specified in articles 501-4(b), 502-4(b), and 503-3(b) of the NEC, NFPA 70 for installation in the United States.

Reviews For G15C0000

Internal Review

While the G15C0000 interface has many features that would make it an excellent purchase, it does not include an additional serial port as the G15C1100 does. Since the G15C0000 does not include the additional port it still has many ports that allow for enough expansion for this interface to excel in all of your communication needs. - AX Control Tech
