12" Red Lion Color Touch Screen Model G12C1100, Designed for Indoor Use. Comes Standard with an Additional Ethernet Port and 4 Isolated Serial Ports. This Series has an Input Voltage Rating of 10, 24, and 30V with this unit's Nominal (HMI Only) Operating Voltage at 13, 14, and 15V.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

3 Year Warranty: Learn More
Sell Surplus: Have a G12C1100 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: G12C1100
  • SKU: G12C1100RL
  • Manufacturer: Red Lion
  • Series: Graphite HMIs

G12C1100

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
12" Red Lion Color Touch Screen Model G12C1100, Designed for Indoor Use. Comes Standard with an Additional Ethernet Port and 4 Isolated Serial Ports. This Series has an Input Voltage Rating of 10, 24, and 30V with this unit's Nominal (HMI Only) Operating Voltage at 13, 14, and 15V.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

3 Year Warranty: Learn More
Sell Surplus: Have a G12C1100 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: G12C1100
  • SKU: G12C1100RL
  • Manufacturer: Red Lion
  • Series: Graphite HMIs

G12C1100 Technical Specifications

Available Power for Modules 33W
Brightness 400 cd/m2
Display Dimensions W307.3mm x H208.3mm
Display Operating Temperature -20 to 60 °C
Display Type WXGA, 16 M Colors
Max Power HMI With Modules 55W
Resolution 1280 X 800
Storage Temperature -20 to 70 °C
Weight 2.29 Kg

Product Description

Model G12C1100 is an indoor touchscreen device from Red Lion. It has 70,000 hours or more of backlight service life and a resolution of 1280 x 800 pixels. It can be mounted using a Chassis Mount and is constructed using cast aluminum. This touchscreen can be operated in temperatures ranging from -20 to 60 degrees Celsius. It is from the HMI touchscreen family and in the Graphite Series. The IP rating is IP66 and the supply voltage is 24 VDC. It is equipped with a web server and TFT LCD color display technology. The touchscreen is 12 inches wide and is resistant to high shocks and vibrations.

Model G12C1100 is capable of running up to 20 protocol conversions at one time from more than 300 industry protocols. It can be used in hazardous environments categorized as UL Class 1 Division 1. It uses Crimson 3.0 software and has an SD slot for data storage and device memory. It also comes with various MQTT connectors built-in. These include Microsoft Azure, Amazon AWX, and Google Cloud. Model G12C1100 has been discontinued by Red Lion but is still available through other sources, such as AX Control. AX Control can buy and sell, as well as repair, these touchscreen devices.

All safety regulations and local codes must be observed by the operators to ensure safety and prevent damage to the instrument or connected systems. If the G12C1100 is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired.

Reviews For G12C1100
Internal Review

While we still recommend the G12C1100 due to its additional ports for expansion, it should be noted that the display of this unit often needs replacement due to a drop, incorrect installation, or dead pixels. A knowledgeable or certified professional can solve most of these issues with cautious installation/operation. - AX Control Inc. Tech Team

Repair Services For G12C1100

Type Lead Time Price Action
Repair Service 1-2 weeks $6499

Our highly skilled technicians can repair your G12C1100. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
