The Red Lion Graphite G10R0000 10-inch High-Resolution Touchscreen HMI

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a G10R0000 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: G10R0000
  • SKU: RL-57451
  • Manufacturer: Red Lion
  • Series: Graphite HMIs

G10R0000 Technical Specifications

Display Brightness/Resolution 400 cd/m2 / 800 X 600 Pixels
External Dimensions 10.84” x 8.57” x 2.06” (275.2 x 217.7 x 52.4 mm)
Max Power HMI Only 15W, 16W, 17W
Max Power with Modules 44W, 46W, 47W
Operating Temperature Standards -20 to 60 °C
Storage Temperature Standards -20 to 70 °C
Weight 2.18 Kg

About the G10R0000

Product G10R0000 is in the Red Lion Graphite Series. This model is a ten-inch high-resolution touch screen that is equipped with:

  • SVGA color technology
  • a design for indoor use only
  • operation or storage in temperatures ranging from -20 to 60 degrees Celsius
  • slight UV sensitivity
  • one Type B USB port
  • seven ports in total
  • an SD slot that can be used for memory and storage
  • up to 20 protocol conversions at the same time
  • forward and store buffering for cloud connectors

This module has multiple built-in MQTT connectors, including Sparkplug, Google Cloud, and Amazon AWS. These MQTT connectors are designed to accelerate specific projects on this device. Model G10R0000 has a backlight with 70,000 hours of service life, and panel mounting capabilities. The NEMA rating for this product is NEMA 4X, while the IP rating is IP66. It is also equipped with OPC UA historical access and an OPC UA client driver. One of the ports on this product is for a 10/100 Base-TX Ethernet connection. Red Lion has discontinued model G10R0000, but we are able to repair and replace these high-end machines.


Frequently Asked Questions about G10R0000

What is the pixelation designated for this G10R0000 HMI?

This G10R0000 has a pixels value of 800x600 pixels.

Does the G10R0000 Operator Interface Touchscreen have any special product features?

One highlight of this G10R0000 in terms of its hardware is its Web-Server.

Reviews For G10R0000

Internal Review
(5.0)

The High-Resolution Display on the G10R0000 and G10R1000 units, along with maintaining a small 10" form factor, provides customers with exceptional clarity found nowhere else in Red Lion HMIs. The G10R0000 unit additionally sports an extreme temperature range that posits a possible installation in some relevant outdoor environments as well. - AX Control Lead Technician

Repair Services For G10R0000

Type Lead Time Price Action
Repair Service 1-2 weeks $5099

Our highly skilled technicians can repair your G10R0000. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
