Compact 7-inch Graphite HMI G07C0000 Specifically made for Indoor Hazardous Locations with a sleek and rugged Aluminum Chassis. This device runs off Crimson software available from Red Lion's website. The input voltage that this model will use is 10, 24, or 30 V.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a G07C0000 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: G07C0000
  • SKU: G07C0000RL
  • Manufacturer: Red Lion
  • Series: Graphite HMIs

G07C0000 Technical Specifications

Catalog Number G07C0000
Series Graphite HMIs
Manufacturer Red Lion
Features Store and Forward Buffering for Cloud Connectors
Storage Temperature -4 to +158 °F
Weather Rating Type 4X Indoor / IP66 Enclosure rating (Face only)
Typical HMI Only Power 7W or 8W
Display Resolution 800 x 480
Display Size 7 inches
Dimensions (in) H5.51 x W7.70 x D2.00
Weight 2.26 lb. (1.03 Kg)
Expansion I/O 1 SD + 5 Module Slots
Input Voltage 10V - 30V

About the G07C0000

Red Lion model G07C0000 is a seven-inch widescreen and touchscreen model with a WVGA color display and a screen resolution of 800 x 480 pixels; the unit was designed to work within the Graphite HMI series. Up to twenty simultaneous protocol conversions are utilized with Red Lion's Crimson 2.0 software, which is available at no charge on Red Lion's website. Three ports are available on the model two high-retention USB ports and a single type B USB port. There are also five slots on the model used for plug-in compatibilities. There are also built-in MQTT connectors; these connectors are as follows:

  • Amazon AWS
  • Google Cloud
  • Ubidots
  • Microsoft Azure
  • Sparkplug
  • Inductive Automation Ignition

All of these connectors are for store and forward buffering.

When the G07C0000 model is being operated, it will be primarily powered by three lithium batteries and has a voltage rating of 24 VDC. The interface also has a protective overlay film rated for use only in indoor applications. There are two temperature ranges that this model can be used in depending on if the model is being stored or operated; the storage temperature range is -4 to 158°F or -20 to 70°C; the operating temperature is -4 to 140°F or -20 to 60°C. These conditions are not the only environmental conditions used with the model; others include the installation category, the altitude, and the shock. For those conditions, refer to the G07-F Red Lion Bulletin.

While the G07C0000 unit can be found on the market in new and used surplus, the model has been discontinued by Red Lion.

Frequently Asked Questions about G07C0000

What is the G07C0000 model?

The G07C0000 model is an Operator Interface Terminal with Plug-In I/O Module Capability. This model is a 7-inch WVGA touchscreen module with a brightness of 500 cd/m².

Is there a difference between the G07C and G07S modules?

Yes! The primary difference between the two modules is that the G07S unit can be used in both indoor and outdoor applications, while the G07C model can only be used in indoor applications. Another difference between the two units is the brightness of the screens on the units; the brightness of the G07S model is 1000 cd/m², with the brightness of the G307C module is 500 cd/m².

Are there differences when using the G07C0000 model in different locations?

There are differences in the mounting of the unit when used in different hazardous locations. When the model is used in a Zone 22 environment, the model must be panel mounted and must be mounted in a Zone 22 IECEx/ATEX-Certified tool accessible enclosure. When the model is in a Zone 2 environment, it must be panel mounted in a Zone 2 IECEx/ATEX-Certified tool-accessible enclosure. The protection ratings between the different locations also differ.

Reviews For G07C0000

Internal Review
(5.0)

If needing a Red Lion model that is easy to use, then the G07C0000 Red Lion interface is the perfect unit. Between easy-to-use interfacing and ease of use with connecting communication modules, the G07C0000 model is the best bang for your buck since the model is sleek and rugged with a variety of cases and ethernet ports. - AX Control Tech

Repair Services For G07C0000

Type Lead Time Price Action
Repair Service 1-2 weeks $2549

Our highly skilled technicians can repair your G07C0000. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
