GMP1SM00

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
Graphite HMI Expansion Module GMP1SM00 is a Graphite PID Module. This module has a single PID loop. The GMP1SM00 has various discrete output combinations. Please note that this controller has an optional DC analog output.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

3 Year Warranty: Learn More
Sell Surplus: Have a GMP1SM00 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: GMP1SM00
  • SKU: GMP1SM00RL
  • Manufacturer: Red Lion
  • Series: Graphite HMI Expansion Modules

GMP1SM00

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
Graphite HMI Expansion Module GMP1SM00 is a Graphite PID Module. This module has a single PID loop. The GMP1SM00 has various discrete output combinations. Please note that this controller has an optional DC analog output.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

3 Year Warranty: Learn More
Sell Surplus: Have a GMP1SM00 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: GMP1SM00
  • SKU: GMP1SM00RL
  • Manufacturer: Red Lion
  • Series: Graphite HMI Expansion Modules

GMP1SM00 Technical Specifications

Accuracy at 18 to 28°C 0.1% of Full Scale
Heater Current Monitor Frequency 50 to 400 Hz
Mounting Method Screws to Host
Number of Alarm Modes Seven
Operating Temperature Range -40 to +75°C
Shock Standards Operation 40 g for UEC 68-2-27
Voltage for Analog DC Output 500 µV
Weight Approx. 224 g (8 oz)

Product Description

Graphite PID Module GMP1SM00 is part of the Graphite HMI Expansion Module Series. This module operates as a single PID loop and has an optional DC analog output. One key feature of this module is its ability to perform effectively any combination of linear or time-proportioning control for heat/cool, heat, or cool applications. The linear output for this module will be assigned to transmit practically any internal variable. When the device has been programmed it will be able to operate independently as long as power is still being applied.

As mentioned previously the GMP1SM00 module is equipped with an optional DC analog output. The output will operate on twenty milliamperes or ten volts and be scaled for re-transmission and/or control purposes as well as independently configured. This module also has a heater current monitor option. The primary purpose of this option is to warn the system of potential heater circuit failure or give an early indication of heater degradation.

As with many of the other modules with the Graphite HMI Expansion Module Series the GMP1SM00 module will be used with Crimson software. This specific module is configured with Windows-compatible Crimson software and allows for routine module re-calibration as well as the commissioning of new systems.

One important thing to note regarding the GMP1SM00 controller is that it can operate in several different modes, some of which are PID, P, PI, or On/Off control mode. The module can also be used with an on-demand Auto-Tune to establish a tuning constant. All of the above information and more can be found in the Red Lion GMPID-K Bulletin.

Reviews For GMP1SM00
Internal Review

The GMP1SM00 controller has an optional DC analog output. This output can be used for re-transmission purposes or independently scaled and configured for control purposes as well. Only GMP1 modules are equipped with the optional DC analog output. - AX Control Technician

Repair Services For GMP1SM00

Type Lead Time Price Action
Repair Service 1-2 weeks $665

Our highly skilled technicians can repair your GMP1SM00. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
