The Red Lion CR30001000000420 Operator Interface Terminal is configured using the Crimson 3.1 software, which is user-friendly and easy to use. The device also has an IP66 NEMA 4X front panel, a web server for remote access, is UL Class 1, Div 2 rated, and has the ability to communicate with over 300 protocols.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

3 Year Warranty: Learn More
Sell Surplus: Have a CR30001000000420 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: CR30001000000420
  • SKU: CR30001000000420RL
  • Manufacturer: Red Lion
  • Series: CR1000 and CR3000 HMIs

CR30001000000420

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (1)
  • Click a star to rate this product
The Red Lion CR30001000000420 Operator Interface Terminal is configured using the Crimson 3.1 software, which is user-friendly and easy to use. The device also has an IP66 NEMA 4X front panel, a web server for remote access, is UL Class 1, Div 2 rated, and has the ability to communicate with over 300 protocols.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

3 Year Warranty: Learn More
Sell Surplus: Have a CR30001000000420 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: CR30001000000420
  • SKU: CR30001000000420RL
  • Manufacturer: Red Lion
  • Series: CR1000 and CR3000 HMIs

CR30001000000420 Technical Specifications

# of Front Panel LEDs 3 (Red, Green, Blue)
# of Rear Ports 2 RS-232, 2 RS-422/485, 2 Ethernet, and 2 USB Host Ports
Altitude Rating Up to 2000 meters
Certifications and Compliances CE, UL/cUL, UL/cUL Hazardous
Display 10.4" Resistive Analog Touchscreen TFT Color LCD
External Dimensions (in) W10.78 x H8.50 x D2.00
Shock Resistance IEC 68-2-27 Operational 30 g
Weather Rating NEMA 4X, IP66 Front Panel Rating

Product Description

The CR30001000000420 is a versatile and powerful human-machine interface (HMI) device that is designed to meet the needs of a wide range of industrial and commercial applications. This model, alternately the CR3000-10000-00420, features a range of connectivity options and advanced features to help users easily monitor and control their systems.

This CR3000 HMI device is equipped with 2 10/100 Ethernet ports, 2 RS-232 serial ports, 2 USB host ports, 2 RS-232/RS-485 serial ports, and 1 USB device port for upload/download. Additionally, the device has an expansion port for select add-on network modules, which allows users to expand the device's connectivity options even further.

Another important feature of the CR30001000000420 is its ability to communicate with over 300 protocols. This includes support for MQTT Connector for Google Cloud, OPC UA Client Driver, and OPC UA Historical Access. This allows users to easily manage multi-vendor environments and integrate the device into their existing systems. Additionally, the device has a Store and Forward Buffering feature for Cloud Connectors, which allows it to buffer data and forward it to the cloud at a later time, ensuring that data is not lost even if the cloud connection is temporarily lost.

The CR3000 operator interface terminal (OIT) also has a range of features that make it easy to use and monitor systems. The device has an 800x600 pixel, 16M color TFT display, which provides clear and detailed information about the system's status. Additionally, the device has a web server for remote access and control, which allows users to monitor and control the system from anywhere with an internet connection. The device also has an SD card slot for data logging and database upload/download, which allows users to easily store and access data.

The CR3000 HMI is configured using the Crimson 3.1 software, which is user-friendly and easy to use. The device also has an IP66 NEMA 4X front panel and is UL Class 1, Div 2 rated, which ensures that it is rugged and durable enough for use in industrial environments. Lastly, the device can operate at a voltage range of 10-30 VDC, which makes it suitable for use in a wide range of applications.

  • CR3000-10000-00420
Reviews For CR30001000000420
Internal Review

The CR3000 and Graphite HMI families by Red Lion have been praised by many for their easy-to-use software interface paired with its durable metal chassis. However, we rarely have this unit in stock as it is such a sought-after device. - AX Control Inc.

Repair Services For CR30001000000420

Type Lead Time Price Action
Repair Service 1-2 weeks $3619

Our highly skilled technicians can repair your CR30001000000420. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
