.25HP Reliance AC Drive | Image

International

Phone

1-919-372-8413

Domestic (US)

1-800-991-7026

6MDAN-1P5111

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures 4.86 (7) Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.86 (7)
  • Click a star to rate this product


.25HP Reliance AC Drive

New Surplus Factory Package
SKU: 5MD1
3 Year Warranty
New Surplus AX Control Package
SKU: 5MD2
3 Year Warranty
Reconditioned
SKU: 5MD3
3 Year Warranty
Repair
$425
SKU: 5MD4
3 Year Warranty

* Learn More About Product Conditions
* Posted pricing available for website purchases only.

Product Conditions

New Surplus Factory Package: A completely unused product that is in the original factory package. The package may have been opened for the purpose of pictures, but the product has never been used or installed.

New Surplus AX Control Package: A completely unused product that has been removed from the original factory package. Often due to shelf wear or previous shipping, the factory package is not adequate and must be replaced with an ideal AX Control product package.

Reconditioned: All products that qualify as reconditioned have completed AX Control's thorough and detailed QA process and meet the requirements of excellent working condition and excellent cosmetic condition.

Product Description

6MDAN-1P5111 is a 230 V, 50/60 Hz, 1-phase MD60 Drive that is manufactured by Reliance Electric. The output current is 1.5 A, the horsepower is 0.25 HP, and the output power is 0.2 kW. There is an integral EMC filter. The frame size is A. When installing the drive, keep it protected with a cooling fan (to avoid dust and metallic particles). Do not expose the drive to a corrosive atmosphere, moisture, or direct sunlight. The enclosure rating can be either IP20/Open Type or IP30/ NEMA 1/ ULType 1.

The MD60 drive can be identified by its model number. “6MD” indicates that the unit is an MD60 Drive. The next letter indicates the drive phase: A= 1-phase and 240 VAC, V= 1-phase and 120 VAC; B= 3-phase and 240 VAC; D= 3-phase and 460 VAC. The next letter is N, which means an IP20 (open type) enclosure rating. The 3 digits after the dash indicate the horsepower and amperes, based on the VAC. At 115 V / 230 VAC: 1P5= 1.5 A and 0.25 HP; 2P3= 2.3 A and 0.5 HP; 4P5= 4.5 A and 1 HP; 6P0= 6.0 A and 1.5 HP; 8P0= 8.0 A and 2 HP; 012= 12.0 A and 3 HP; 017= 17.5 A and 5 HP. At 460 VAC, 1P4= 1.4 A and 0.5 HP; 2P3= 2.3A and 1 HP; 4P0= 4 A and 2 HP; 6P0= 6 A and 3 HP; 8P7= 8.7 A and 5 HP. The next number is 1 and is Reserved. The next number is either 1 (Internal Filter) or 0 (No Filter). The last number is 1 and is Reserved.

6MDAN-1P5111 Manuals, White Papers, Data Sheets, and Troubleshooting

6MDAN-1P5111 Technical Specifications

Manufacturer Reliance Electric
Series MD60
Part Number 6MDAN-1P5111
HP 0.25 HP
Input Voltage 115-230 VAC
Enclosure NEMA 1 or Chassis
Hz 50/60Hz
kW 0.2kW
Filter/No Filter Internal Filter
Labeling UL Listed, IEC Certified

Frequently Asked Questions about 6MDAN-1P5111

How do I change the Stop Mode parameter on my 6MDAN-1P5111 drive?
To change the Stop Mode on your MD60 6MDAN-1P5111 drive, you choose parameter P037. The P037 Stop Mode Parameter allows you a range of 0-7 different ways to stop your 6MDAN-1P5111 drive. The Stop Mode number ranges are as follows:
0= Ramp, Clear Fault
1= Coast, Clear Fault
2= DC Brake, Clear Fault
3= DC Brake with Shutoff, Clear Fault
4= Ramp
5= Coast
6= DC Brake
7= DC Brake with Shutoff
The default Stop Mode for the MD60 6MDAN-1P5111 drive is 1.
What is the power dissipation on an 6MDAN-1P5111 drive?
The power dissipation on a 6MDAN-1P5111 drive is 25 IP20 Open Watts.
What size wires should the 6MDAN-1P5111 drive have for power terminal block connections?
A 6MDAN-1P5111 drive should have a maximum wire size of 5.3mm^2 (10 AWG) and a minimum wire size of 1.3mm^2 (16 AWG) for a terminal block to accept them. Anything above or below the maximum and minimum wire sizes will not work for a 6MDAN-1P5111 drive.
Is there a way to output power a 6MDAN-1P5111 MD60 drive?
MD60 drives were intended to be controlled through input signals to start and stop the motor. You should not use a device that routinely disconnects then reapplies output power to the motor to start and stop your 6MDAN-1P5111 drive. Your 6MDAN-1P5111 drive needs your command of controls through input signals.
Does AX Control troubleshoot and repair 6MDAN-1P5111 drives?
We offer in-house repair options for all MD60 drives and would be happy to repair your 6MDAN-1P5111. Give us a call and ask our sales representative for an estimated repair time and quote on your 6MDAN-1P5111.
Where can I easily access fault codes and help with troubleshooting for my 6MDAN-1P5111?
AX Control can send you a link to the MD60 AC Drive User Manual which explains how to manually and automatically clear faults, and provides you troubleshooting tables to solve any issues with your 6MDAN-1P5111.
Is there a manual to guide me through the installation process for my 6MDAN-1P5111?
Yes. We can send you the link to the MD60 AC Drive User Manual which will guide you through the full installation process for your 6MDAN-1P5111.
What frame size is the MD60 6MDAN-1P5111?
The MD60 6MDAN-1P5111 has an A frame size.
