6KE$32DBR010

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.80 (5)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.80 (5)
  • Click a star to rate this product
AF-300E$ 230VAC 10HP Dynamic Braking Resistor

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

2 Year Warranty: Learn More

Sell Surplus: Have a 6KE$32DBR010 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

6KE$32DBR010

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.80 (5)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.80 (5)
  • Click a star to rate this product
AF-300E$ 230VAC 10HP Dynamic Braking Resistor

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

2 Year Warranty: Learn More

Sell Surplus: Have a 6KE$32DBR010 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Product Description

The AF-300E$ drive family includes the General Electric Fuji Electric 6KE$32DBR010 dynamic braking resistor.The required input voltage is 200-230V. The 6KE$32DBR010 operates at 10 HP. The enclosure is a mill galvanized finish and the enclosure includes a terminal block.

This optional device is sized for use with the General Electric Fuji Electric 6K3$243020X1A1 adjustable frequency drive.  The 6K3$243020X1A1 adjustable frequency drive is matched with the  6KE$32DBR010 dynamic braking resistor to obtain the maximum results.

The 6K3$243020X1A1 adjustable frequency drive operated in constant torque applications can obtain faster process and product cycle times that otherwise would be unattainable without the use of the dynamic braking resistor option. To improve the safety of personnel and equipment, particular processes may need to have a quick stop feature so the process is terminated quickly. This helps prevent injury and damage to equipment.

For the 6KE$32DBR010 dynamic braking resistor, the braking torque is 100 percent in the built in resistor and 150 percent in the optional resistor. In the CT applications, the duty factor is 5 and the braking time is 10 seconds. For VT applications, the duty factor is 3.5 and the braking time is 7 seconds. The maximum KW is 0.9 and the total OHms is 15.

Repair Services For 6KE$32DBR010

Type Lead Time Price Action
Repair Service 1-2 weeks Ask Get Quote

Our highly skilled technicians can repair your 6KE$32DBR010. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More

6KE$32DBR010 Manuals, White Papers, Data Sheets, and Troubleshooting
