IS420UCSBH3A

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures 4.3 (13) Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.3 (13)
  • Click a star to rate this product


General Electric Mark VIe Controller IS420UCSBH3A is equipped with a 1200 MHz EP8057 Intel Processor that is used in high-speed application designs. This model does not feature fans for cooling but has a built-in battery source.

New Surplus Factory Package
$9970
SKU: 60MVMVCS1
3 Year Warranty
Order Before 3PM EST
Rush Available
1 in Stock
New Surplus AX Control Package
SKU: 60MVMVCS2
3 Year Warranty
Reconditioned
SKU: 60MVMVCS3
3 Year Warranty
Repair
$1834
SKU: 60MVMVCS4
3 Year Warranty

* Learn More About Product Conditions
* Posted pricing available for website purchases only.

Product Conditions

New Surplus Factory Package: A completely unused product that is in the original factory package. The package may have been opened for the purpose of pictures, but the product has never been used or installed.

New Surplus AX Control Package: A completely unused product that has been removed from the original factory package. Often due to shelf wear or previous shipping, the factory package is not adequate and must be replaced with an ideal AX Control product package.

Reconditioned: All products that qualify as reconditioned have completed AX Control's thorough and detailed QA process and meet the requirements of excellent working condition and excellent cosmetic condition.

About the IS420UCSBH3A

The IS420UCSBH3A controller is another version of the UCSB controller from the Mark VIe Series produced by General Electric. This controller is described as a Mark VIe or MarkStat Controller in the GEH-6725 Mark VIe and Mark VIeS Controls Equipment HazLoc Instruction Guide. This device is equipped with a 1200 MHz EP80579 Intel Microprocessor. This controller is very similar to the UCSC controller in the Mark VIe Series, and while the two controllers have different hardware forms the software forms on the two controllers are nearly identical. Some of the advantages to a controller such as this are the lack of battery and fan as well as the lack of required jumper settings.

The IS420UCSBH3A controller has a variety of LEDs on the front plate, some of which are:

  • OT which displays amber when the internal components have surpassed the recommended limit

  • ON which indicates the status of the restoration process

  • DC which displays a solid green LED when the controller has been chosen as the designed controller

  • ONL which will be solid green when the controller is online and running the application code

All of the above-listed LEDs are used to indicate the controllers status, information on these LEDs can be found in the GEH-6855 Volume I Mark VIeS Functional Safety Systems System Guide in chapter eight and specifically on page one hundred fifty-nine and one hundred sixty.

This controller also has specific location certifications and standards needed to operate reliably. When mounted in Class I, Division 2, Groups A, B, C, or D, the IS420UCSBH3A controller requires ANSI/ISA-12.12.01-2015 or CAN/CSA-C22.2 No. 213-15 standards. For more information on the different location standards refer to the GEH-6725 HazLoc Instruction Guide.

IS420UCSBH3A Technical Specifications

Model Number IS420UCSBH3A
Wire Sizes 28 to 16 AWG
Weight approx. 2.9 lbs
Processor Type 1200 MHz EP80579 Intel
Operating Temperature 0 to 65 °C
Manufacturer General Electric
Input Voltage 24/28 VDC
Functional Abbreviation UCSB
Dimensions H 6.4 in x W 8.1 in x D 1.4 in

Reviews For IS420UCSBH3A

Internal Review
(4.0)

The IS420UCSBH3A model has limited information, the information that can be found relates to the processor type as well as locations in which the device can be mounted. Refer to the GEH-6855 manual as well as the GEH-6725 HazLoc manual for information. - AX Control Technician
