This IS420UCECH1B Port Expansion/Controller Module was manufactured for General Electric's Mark VIe and Mark VIes Turbine Control System Series.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a IS420UCECH1B to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: IS420UCECH1B
  • SKU: IS420UCECH1BGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark VIe & Mark VIeS Control Systems

IS420UCECH1B Technical Specifications

Manufacturer General Electric
Series Mark VIe & VIeS
Functional Part Number IS420UCECH1B
Functional Description IS420UCECH1B Port Expansion/Controller Module
Port Quantity Twelve Ports
PCB Protection Conformal PCB Coating, Chassis
Manufacturer Location Germany
Primary Functional Revision B

About the IS420UCECH1B

Hardware Tips and Specifications

While this IS420UCECH1B Port Expansion/Controller Module device has a storied history in terms of its specific series's interlocking market role, this IS420UCECH1B Port Expansion/Controller Module device here is really not surrounded by too much original instructional manual material on the internet.

With this being the case, the IS420UCECH1B Port Expansion/Controller Module functional product number serves to expose a number of this IS420UCECH1B Port Expansion/Controller Module device's important base hardware details, through a typical selection of hardware components. This IS420UCECH1B Port Expansion/Controller Module device's product number is kicked off through its inclusion of the IS420 series that that does confirm this device's special modular assembly version, and includes:

  • the UCEC H1 tag on its front port plate
    • it must be assumed that this is included in its assembly as some sort of previous reference or vestigial marking
  • twice the number of possible port connections to models such as the IS420UCSCH1A or IS420UCSCH1B Modules

The unique platforms that this IS420UCECH1B Port Expansion/Controller Module device supports include:

  • EX2100 (Excitation Control)
  • Embedded Field Agent or EFA

Frequently Asked Questions about IS420UCECH1B

Does this IS420UCECH1B modular assembly make use of any LED indicators on its front plate?

Yes. This IS420UCECH1B product's front is adorned with a series of LED diagnostic indicators, with various labels such as FAOK, Boot, PHY PRES, and the rudimentary On.

How many total ports does this IS420UCECH1B device's assembly include?

Twelve total HSSL ports have been included in this IS420UCECH1B device's assembly; again all visibile on its front plate as pictured above.

What does a Conformal-style PCB protective coating really mean?

The IS420UCECH1B device's conformal PCB coating is a thin layer of chemical PCB protection extended to this IS420UCECH1B device's entire base PCB.

Is this an EEPROM Circuit Board or an EEPROM?

This IS420UCECH1B device is an EEPROM Board, as the IS420UCECH1B functional product number's initial tag seems to suggest.

Reviews For IS420UCECH1B

Internal Review
(5.0)

This IS420UCECH1B product offering, functionally definable as the IS420UCECH1B Port Expansion/Controller Module, is a critical Mark VIe or Mark VIeS Turbine Control System Series product offering that should be well-protected for potential hazardous location or HazLoc mounting strategies given its sturdy vented metallic chassis. Said chassis also features two factory-drilled screw holes with widened slots for convenient mounting. This Port Expansion/Controller Module device's COM, DisplayPort, and IICS Cloud Ports are on its bottom, and it can be repaired here as well. - AX Control Lead Technician
