IS420PUAAH1A Universal Input/Output Module

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a IS420PUAAH1A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: IS420PUAAH1A
  • SKU: GBTC-53631
  • Manufacturer: GE Gas Power
  • Series: Mark VIe & Mark VIeS Control Systems

IS420PUAAH1A Technical Specifications

Manual GEH-6855 Vol I
Series Mark VIe/Mark VIeS
Product Type Universal Input-Output Pack
Part Number IS420PUAAH1A
Operating Temperature -40 to +158 °F
Model Number IS420PUAAH1A
Manufacturer General Electric
Humidity 5-95% non-condensing
Functional Abbreviation PUAA
ControlST Software Suite Version V07.02.00C or Later

About the IS420PUAAH1A

Various IS420PUAAH1A I/O Module Compatibilities

The IS420PUAAH1A is a Universal Input/Output Module from General Electric. It is designed for use within distributed control systems and BOP (balance of power) control systems.  Typically, it is used within the Mark VIe control system and is similar to the YUAA board used within a Mark VIeS system. These systems were the most advanced and latest released Speedtronic systems from GE for the management of gas and steam turbine systems. The IS420PUAAH1A is designed for use with ControlST version 7.02.00C or later. The IS420PUAAH1A allows users to use fewer panels and have a smaller footprint for their system by offering black sections that can be independently wired, which allows for channel-by-channel commissioning.


IS420PUAAH1A Device Channels Offered

The module has sixteen Simplex analog channels. These can be configured individually as the following:

  • Thermocouple I/O
  • RTD I/O
  • Voltage Input
  • 4-20 mA current input
  • 0-20 mA current output
  • Pulse accumulator
  • Digital input

The IS420PUAAH1A supports a frame rate of 10ms.  Auto-reconfiguration is supported. The unit is hot-swapped replacement supported. It is designed to operate in temperatures ranging from -40 to 158 degrees Fahrenheit in 5% to 95% relative humidity, non-condensing. Normal scan time is 5 ms and measurement accuracy is better than 0.1% within the specified temperature range. For additional information about the IS420PUAAH1A, please refer to user guides and manuals originally published by General Electric. These publications will have detailed, important information regarding the handling and installation of this equipment.


Reviews For IS420PUAAH1A

Internal Review
(4.0)

While the IS420PUAAH1A is used within the Mark VIe System information is limited. Due to its similarities to the YUAA pack, the information provided for the YUAA I/O pack is often used for the PUAA I/O pack. For more information refer to the GEH-855 manual. - AX Control Technician

Repair Services For IS420PUAAH1A

Type Lead Time Price Action
Repair Service 1-2 weeks $2061

Our highly skilled technicians can repair your IS420PUAAH1A. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
