Industrial Ethernet Switch IS420ESWBH5A is part of the Mark VIe/VIeS System produced by General Electric. This pack has two 100Base-LX10 single-mode fiber ports. The IS420ESWBH5A pack can only be replaced by a model that has the exact same part number.

New Surplus Factory Package
SKU: 52MVMVCS1
3 Year Warranty
New Surplus AX Control Package
SKU: 52MVMVCS2
3 Year Warranty
Reconditioned
SKU: 52MVMVCS3
3 Year Warranty
Repair
$2148
SKU: 52MVMVCS4
3 Year Warranty

* Learn More About Product Conditions
* Posted pricing available for website purchases only.

Product Conditions

New Surplus Factory Package: A completely unused product that is in the original factory package. The package may have been opened for the purpose of pictures, but the product has never been used or installed.

New Surplus AX Control Package: A completely unused product that has been removed from the original factory package. Often due to shelf wear or previous shipping, the factory package is not adequate and must be replaced with an ideal AX Control product package.

Reconditioned: All products that qualify as reconditioned have completed AX Control's thorough and detailed QA process and meet the requirements of excellent working condition and excellent cosmetic condition.

Product Description

The IS420ESWBH5A IONet Switch is the fifth and final version of the ESWB hardware. This switch is the same as the previous models except for its fiber ports, this switch has two fiber ports. The two fiber ports on this switch are 100Base-LX10 single-mode fiber ports with LC-type connection; please note that as these ports are single-mode fiber ports an additional single-mode transducer is required; the part number for this transducer is 65G2100–008 which is manufactured by General Electric.

The operation for this pack is mainly centered on the ability to buffer packets. The IS420ESWBH5A pack is considered a level-one Ethernet switch and will have a continuous stream of multicast and/or broadcast packets that will buffer incoming streams and send them out upon complete reception. Please note that when multiple streams are coming in only one stream can be relieved at a time, all of the remaining streams will have to be buffered at a later time.

This switch has the ability to be mounted in multiple locations, hazardous and non-hazardous alike as well as in two different orientations. The hazardous locations for the IS420ESWBH5A switch are class one, division two; class two, zone two, and ATEX. The switch will be DIN-rail mounted and positioned on the long edge of the switch either parallel or perpendicular to the rail. When parallel mounted a 259B2451BVP1 clip is required. If this switch is replacing another in a third-party situation the switch can be panel mounted, panel mounting will use the screws that were used with the previous part.

IS420ESWBH5A Technical Specifications

Manufacturer GE Energy
Weight 1lbs 8oz
Product Type Mark VIe IONet Switch
Part Number IS420ESWBH5A
Operating Vibration 1.0 G Horizontal, 0.5 G Vertical
Operating Temperature -40 to +158 °F
Absolute Max Current < 1.0 A
Input Voltage 28 VDC
Functional Abbreviation ESWB
Fiber Ports 2, 100Base-LX10 Single-Mode Fiber Ports
Dimensions H 18.8 cm x W 8.6 cm x D 5.6 cm
Conformal Coating Resistant to Corrosion

Reviews For IS420ESWBH5A

Internal Review
(5.0)

This switch is the fifth and final version of the sixteen 10/100Base-TX copper port switch. This switch is used to help with several different speeds and reliability. There are a variety of features needed to allow for high-speed and reliable functions. - AX Control Tech Team
