The IS420ESWBH1AE IONet Switch Module

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS420ESWBH1AE to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS420ESWBH1AE
SKU: GBTC-59357

Manufacturer: GE Boards & Turbine Control
Series: Mark VIe & Mark VIeS Control Systems

Description
Repairs
Warranty
Manuals

IS420ESWBH1AE Technical Specifications

Functional Description	IS420ESWBH1AE IONet Switch Module
Manufacturer	General Electric
Series	Mark VIe & VIeS
LED Count	5 LEDs
Base PCB Coating	Conformal Coating
Mark VIe/S Grouping	Group 1
Chassis Style	Side-Vented
Revision Total	2 Revisions

About the IS420ESWBH1AE

The IS420ESWBH1AE IONet Switch Module featured here was originally designed and created for General Electric, for insertion in the assembly of their Mark VIe or Mark VIeS Turbine Control System Series. As this is true, its IS420ESWBH1AE functional product numberr has also been designed to indicate several critical IS420ESWBH1AE IONet Switch Module hardware traits, such as its:

IS420 modular Mark VIe/S assembly
ESWB functional product acronym
Group 1 Mark VIe/S Series grouping
Spray-on conformal PCB coating
A-rated primary revision
E-rated secondary revision

It should be noted that both of this IS420ESWBH1AE IONet Switch Module's revisions can be classified as functionality-focused based off of standard General Electric Mark Series product naming conventions.

IS420ESWBH1AE Switch Inspection

A simple visual inspection of the IS420ESWBH1AE IONet Switch Module yields many other important hardware inclusions and specifications, such as its:

16 total Ethernet Ports
SFP1 and SFP2 Ports
Four LED indicators
Side-vented chassis

Frequently Asked Questions about IS420ESWBH1AE

What are this IS420ESWBH1AE IONet Switch Module's LEDs labeled as?

This IS420ESWBH1AE IONet Switch Module makes use of the ACT1, ACT2, LNK1, and LNK2 LEDs.

Is the IS420ESWBH1AE IONet Switch Module waterproof?

No. This IS420ESWBH1AE IONet Switch Module is probably the furthest thing from a waterproof product, given its significantly-vented chassis and front consisting of open Ethernet ports.

Reviews For IS420ESWBH1AE

Internal Review

(5.0)

The IS420ESWBH1AE IONet Switch Module here from General Electric has one fiber port in its assembly, which seems small compared to its large selection of Ethernet ports. It also has a PWR LED separate from the rest for the most basic diagnostic readout. - AX Control Lead Technician
