The IS230TRLYH1B is a Discrete Output Module from the Mark VIe Series manufactured by GE Energy

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS230TRLYH1B to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS230TRLYH1B
SKU: GBTC-58862

Manufacturer: GE Boards & Turbine Control
Series: Mark VIe & Mark VIeS Control Systems

Description
Repairs
Warranty
Manuals

IS230TRLYH1B Technical Specifications

Part Number	IS230TRLYH1B
Product Type	Discrete Output Module
Manufacturer	GE Energy
Series	Mark VIe
Base Product Coating	Conformal Base Coat
I/O Pack Status	3 PDOA Packs
Base Assembly	Modular Standard IS230
Cousin Mark Series Device	TNRL

About the IS230TRLYH1B

The IS230TRLYH1B is a Discrete Relay Output that was manufactured by GE Energy for use in the Mark VIe Series. The module is made up of an IS200TRLYH1B terminal board and three PDOA I/O packs.

IS230TRLYH1B Specifications

The IS230TRLYH1B holds 12 plug in magnetic relays on the terminal board. There are different configurations for the relays.

First six relays are configured for either dry, Form-C contact outputs or to drive external solenoids
Next five relays are unpowered isolated Form-C contacts
Last output is an isolated Form-C contact used for special applications

There are three PDOA packs attached to the terminal board given its TMR status. Connectors JR1, JS1, and JT1 are used for these packs.

Frequently Asked Questions about IS230TRLYH1B

Can the IS230TRLYH1B be used in any simplex systems?

No, the IS230TRLYH1B cannot be used in any simplex systems. The module is only designed for TMR systems.

Can the terminal blocks on the IS230TRLYH1B be removed?

Yes, the terminal blocks can be removed. This makes maintenance of the board easier.
