The IS230TNRLH3E is a Discrete Output Module from the Mark VIe Series that was manufactured by GE Energy

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a IS230TNRLH3E to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: IS230TNRLH3E
  • SKU: GBTC-58874
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark VIe & Mark VIeS Control Systems

IS230TNRLH3E Technical Specifications

Part Number IS230TNRLH3E
Product Type Discrete Output Module
Manufacturer GE Energy
Series Mark VIe
Functional Personal Abbreviation TNRL
Functional Rev E-Rated Revision
Mark Series Grouping Commonness Uncommon
General I/O Redundancy TMR Redundant
PDOA Packs Three I/O PDOA Packs

About the IS230TNRLH3E

The IS230TNRLH3E is a Discrete Output Module manufactured by GE Energy for use in the Mark VIe Series. This module is made of an IS200TRLYH3E terminal board and three PDOA I/O packs.

IS230TNRLH3E Specifications

The IS230TNRLH3E has a 12 output relay terminal board that has solid state relays. All 12 circuits have isolated output voltage feedback. The IS230TNRLH3E is designed for 125 V dc applications. The wires for the 12 solenoids will directly connect to the terminal block on the terminal board.

There are several diagnostic features on the IS230TNRLH3E. Some of these are:

  • Monitoring output of each relay
  • Monitoring solenoid excitation voltage
  • Monitoring hardware compatibility

Faults will be generated through the I/O packs connected to the terminal boards.

Frequently Asked Questions about IS230TNRLH3E

Is there user solenoid power distribution on the IS230TNRLH3E?

No, user solenoid power distribution is not included on the IS230TNRLH3E.

Can the IS230TNRLH3E be used in simplex systems?

No, the IS230TNRLH3E only works in TMR systems, which is indicated by the three I/O packs the module has.
