What is the nominal voltage rating for the IS230TNIDH2A?

The IS230TNIDH2A has a nominal voltage rating of 24 V dc.

What kinds of faults can the IS230TNIDH2A detect?

The IS230TNIDH2A can determine the contact input state, as well as an unplugged cable.

DS200AAHA1	GE Turbine Control	Mark V

DS200AAHA1	GE Turbine Control	Mark V

Home GE Boards & Turbine Control Mark VIe & Mark VIeS Control Systems IS230TNIDH2A

About | Product Specifications | FAQs

IS230TNIDH2A

4.93 (14)
Click a star to rate this product

4.93 (14)
Click a star to rate this product

The IS230TNIDH2A is a Discrete Input Module manufactured by GE Energy for use in the Mark VIe Series

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS230TNIDH2A to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS230TNIDH2A
SKU: GBTC-58839

Manufacturer: GE Boards & Turbine Control
Series: Mark VIe & Mark VIeS Control Systems

Description
Repairs
Warranty
Manuals

IS230TNIDH2A Technical Specifications

Part Number	IS230TNIDH2A
Product Type	Discrete Input Module
Manufacturer	GE Energy
Series	Mark VIe
Personal Redundancy (I/O)	Simplex Redundancy
Mark VIe/S Grouping	Group 2
V DC Rating	24 V DC
Revision Commonness	Common A-Rated

About the IS230TNIDH2A

The IS230TNIDH2A is a Discrete Input Module that was manufactured by GE Energy for use in the Mark VIe Series of turbine controls. This module is made up of an IS200TICI terminal board and a PDIA I/O pack. The IS230TNIDH2A can only be used for simplex applications.

IS230TNIDH2A Specifications

The IS230TNIDH2A has 24 voltage detection circuits. These circuits can be used to sense a range of voltage across different components. These are:

Relay contacts
Fuses
Switches

The IS230TNIDH2A does not have any jumpers, which means no configurations can be made to the module. The IS230TNIDH2A also does not allow for any option boards to be connected to the terminal board.

Reviews For IS230TNIDH2A

Internal Review

(5.0)

The IS230TNIDH2A has removable terminal blocks, which allows for easier maintenance of the board. The module has three connectors, but only JR1 will be used for the PDIA I/O pack. The inputs on the IS230TNIDH2A are electrically isolated from all other inputs and other electronics. - AX Control Lead Technician
