The IS230TNCIH6C is a Contact Input Module from the Mark VIe Series by GE Energy

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS230TNCIH6C to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS230TNCIH6C
SKU: GBTC-58835

Manufacturer: GE Boards & Turbine Control
Series: Mark VIe & Mark VIeS Control Systems

Description
Repairs
Warranty
Manuals

IS230TNCIH6C Technical Specifications

Product Number	IS230TNCIH6C
Part Type	Contact Input Module
Manufacturer	GE Energy
Product Series	Mark VIe
I/O Packs	PDIA Packs
Greater Mounting Assembly	DIN-Rail
Terminal Strips	2 Strips
Grouping Commonality	Uncommon
Redundancy (I/O Pack)	TMR or Triple Mod. Redundant

About the IS230TNCIH6C

The IS230TNCIH6C is a Contact Input Module that was manufactured by GE Energy. This module can be used in the Mark VIe Series. The IS230TNCIH6C is comprised of a TBCI terminal board and three PDIA I/O packs.

IS230TNCIH6C Specifications

The IS230TNCIH6C runs on 48 V dc contact input excitation power. There are 24 dry contact inputs on the module that are wired to two barrier style terminal blocks on the TBCI terminal board. The IS230TNCIH6C has a variety of connectors for different purposes. Some of the connectors are:

Connector JE1
Connector JE2
Connector JR1
Connector JS1
Connector JT1

JE1 and 2 are used to connect the power source to the module. The other three connectors are used to connect the I/O packs to the module.

Reviews For IS230TNCIH6C

Internal Review

(5.0)

The IS230TNCIH6C has several diagnostic features that allow for users to know if there are any faults with the module. One of these includes a loss of contact input excitation voltage. This is important because this excitation voltage allows the module to run. - AX Control Lead Technician
