IS230TNAOH2C

4.94 (16)
Click a star to rate this product

4.94 (16)
Click a star to rate this product

The IS230TNAOH2C is an Analog Output Module from the Mark VIe Series manufactured by GE Energy

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS230TNAOH2C to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS230TNAOH2C
SKU: GBTC-58811

Manufacturer: GE Boards & Turbine Control
Series: Mark VIe & Mark VIeS Control Systems

Description
Repairs
Warranty
Manuals

IS230TNAOH2C Technical Specifications

Part Number	IS230TNAOH2C
Product Type	Analog Output Module
Manufacturer	GE Energy
Series	Mark VIe
Terminal Board	IS200TBAO
Revisions Made	1 C-Graded Functional Rev
PAOC Packs	2 PAOC I/O Packs
I/O Pack Personal Redundance	Simplex I/O Redundancy
Number of Outputs	16 Outputs

About the IS230TNAOH2C

The IS230TNAOH2C is an Analog Output Module from the Mark VIe Series. This module was manufactured by GE Energy. The IS230TNAOH2C is comprised of an IS200TBAO terminal board and two PAOC I/O packs. The IS230TNAOH2C can only be used in simplex applications, despite its two I/O packs.

IS230TNAOH2C Specifications

The IS230TNAOH2C supports 16 analog outputs that have a current rating of 0-20 mA. The outputs are single ended.

There are protection features on the outputs. These are noise suppression features that protect against:

Surge
High frequency noise

The IS230TNAOH2C has two barrier type terminal blocks that the outputs are wired to.

Frequently Asked Questions about IS230TNAOH2C

How is the output current on the IS230TNAOH2C measured?

The output current on the IS230TNAOH2C is measured by the voltage drop across a resistor on the terminal board.

Is there a diagnostic test for the outputs on the IS230TNAOH2C?

Yes, there is a diagnostic test on the IS230TNAOH2C that tests whether the outputs are healthy or not.

Reviews For IS230TNAOH2C

Internal Review

(4.0)

The IS230TNAOH2C can only be used in simplex systems, making this a four star part. The module only being available for simplex use limits the applications that the IS230TNAOH2C can be used with. The IS230TNAOH2C also requires two PAOC packs despite its simplex design. - AX Control Lead Technician
