IS230TNAIH2C

4.93 (14)
Click a star to rate this product

4.93 (14)
Click a star to rate this product

The IS230TNAIH2C is an Analog I/O Module from the Mark VIe Series manufactured by GE Energy

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS230TNAIH2C to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS230TNAIH2C
SKU: GBTC-58801

Manufacturer: GE Boards & Turbine Control
Series: Mark VIe & Mark VIeS Control Systems

Description
Repairs
Warranty
Manuals

IS230TNAIH2C Technical Specifications

Part Number	IS230TNAIH2C
Product Type	Analog I/O Module
Manufacturer	GE Energy
Series	Mark VIe
IS230TNAIH2C Pack Redundancy	TMR (Triple Modular Redundant)
Revision Total	One C-rated Functional Rev
Discrete or Analog	Analog
Input or Output	Both Input and Output
Terminal Board	IS200TBAI

About the IS230TNAIH2C

The IS230TNAIH2C is an Analog I/O Module that was manufactured for the Mark VIe Series by GE Energy. This module is comprised of an IS200TBAI terminal board and three PAIC I/O packs. This module requires three packs because it can only be used with TMR applications.

IS230TNAIH2C Specifications

The IS230TNAIH2C supports 10 analog inputs and 2 analog outputs. The analog inputs can accommodate four types of transmitters. These transmitters are:

Externally powered transmitters
2 wire transmitters
3 wire transmitters
4 wire transmitters

The first analog output can be set up as either 0-20 mA current or 0-200 mA current. The current can change by reconfiguring the jumpers on the terminal board.

Frequently Asked Questions about IS230TNAIH2C

How many total channels does the IS230TNAIH2C have?

The IS230TNAIH2C has 12 total channels.

What diagnostic features does the IS230TNAIH2C have?

The IS230TNAIH2C has several diagnostic features. One of these features monitors the status of the outputs and will create a fault if one of the outputs goes unhealthy. Another features tests for hardware compatibility.

Reviews For IS230TNAIH2C

Internal Review

(5.0)

The IS230TNAIH2C has noise suppression circuitry for its inputs and outputs. This protects against surge and high frequency noise that could interfere with the work of the inputs and outputs. The IS230TNAIH2C has 3 connectors that allow for the needed I/O packs to be added to the terminal board. - AX Control Lead Technician
