IS230TNAIH1C

4.93 (15)
Click a star to rate this product

4.93 (15)
Click a star to rate this product

The IS230TNAIH1C is an Analog I/O Module that was manufactured by GE Energy for the Mark VIe Series

AVAILABILITY:

IN STOCK
SHIPS IN 1-2 WEEKS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS230TNAIH1C to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS230TNAIH1C
SKU: GBTC-58799

Manufacturer: GE Boards & Turbine Control
Series: Mark VIe & Mark VIeS Control Systems

Description
Repairs
Warranty
Manuals

IS230TNAIH1C Technical Specifications

Part Number	IS230TNAIH1C
Product Type	Analog I/O Module
Manufacturer	GE Energy
Series	Mark VIe
Abbreviation	TNAI
Terminal Board	IS200TBAI
Revision Type	C-rated Functional
Mark VIe Group	Group 1

About the IS230TNAIH1C

The IS230TNAIH1C is an Analog Input/Output Module that was manufactured by GE Energy. This module is part of the Mark VIe Series. The IS230TNAIH1C is comprised of an IS200TBAI terminal board and a PAIC I/O Pack.

IS230TNAIH1C Specifications

The IS230TNAIH1C supports 10 analog inputs and 2 analog outputs. The IS230TNAIH1C is designed to be used with simplex applications, which means that one I/O pack will be used with the module.

The analog outputs can be set up for two different current output ratings. These are:

0-20 mA
0-200 mA

The analog inputs can be used with several types of transmitters, including both two and three wire transmitters.

Frequently Asked Questions about IS230TNAIH1C

Does the IS230TNAIH1C have noise suppression circuitry?

Yes, the IS230TNAIH1C has noise suppression circuitry on its inputs that work to protect against surge and high frequency noise.

How much power does the IS230TNAIH1C give transducers?

The IS230TNAIH1C provides 24 V dc power to all transducers.

Reviews For IS230TNAIH1C

Internal Review

(5.0)

The IS230TNAIH1C has 12 total channels that have noise suppression features. The IS230TNAIH1C can only be used in simplex applications, which means only one PAIC pack is connected to the module. The IS230TNAIH1C also has several diagnostic features that are important. One of these includes a fault that occurs if one of the outputs goes unhealthy. - AX Control Lead Technician
